General Information

• Part Number: PCB‑I‑E‑144 (also referenced as PCB‑144)

• Manufacturer: Contrel

• Product Type: Industrial PCI video converter / image pattern generator card

• Compatible System: SI300N industrial motherboard

• Revision: VER 1.0

• Application: Industrial display systems, image generation, DVI signal conversion, factory automation, machine vision

Electrical & Interface Specifications

• Bus Interface: PCI (standard 32‑bit PCI slot)

• Video Input: DVI‑I (digital + analog)

• Video Output: DVI, plus analog RGB/VGA via breakout cable

• Connector: DVI‑I female, RJ45 (Ethernet), multi‑pin header for flat cables

• Power Supply: +3.3 V / +5 V from PCI slot

• Power Consumption: Typical ~5 W (max 8 W)

• Operating System Support: Windows XP/7/10, Linux (kernel 3.x+)

Mechanical Parameters

• Form Factor: Standard full‑size PCI card

• Dimensions (L × W × H): Approx. 170 mm × 100 mm × 20 mm

• Weight: ~1.0 kg

• Mounting: Standard PCI slot bracket (metal, single‑slot)

Environmental Specifications

• Operating Temperature: 0 °C to +50 °C

• Storage Temperature: −40 °C to +70 °C

• Relative Humidity: 10%–85% RH, non‑condensing

• Shock/Vibration: Industrial grade (compliant with IEC 60068‑2‑6)

Main Features

• DVI ↔ analog RGB/VGA real‑time conversion

• Onboard image pattern generator for display testing

• Compatible with SI300N and other industrial motherboards

• PCI plug‑and‑play, no external power required

• Robust industrial design for 24/7 continuous operation

• Supports resolutions up to 1920×1080 @ 60 Hz
