Endress+Hauser Proline Promass E 200 8E2B25-17M9/0

The 8E2B25-17M9/0 is a loop-powered Coriolis mass flowmeter from Endress+Hauser Promass E 200 series, DN25 size. This 8E2B adopts dual-tube Coriolis principle, directly measures mass flow, density and temperature simultaneously, no straight inlet/outlet pipe required. The order string 17M9/0 defines wetted material, process connection, output protocol, hazardous certification and firmware variant for this specific unit.

This 8E2B25 supports loop-powered 4-20mA HART, also optional PROFIBUS PA or FOUNDATION Fieldbus. It delivers high accuracy for liquid and gas measurement, built-in Heartbeat Technology for continuous self-diagnosis and verification without process shutdown. IP66/IP67 housing, ATEX, IECEx, INMETRO and SIL approvals are available. Touch-control local display supports on-site setup and reading, commissioning can also be done via SmartBlue Bluetooth App. Wetted part 904L stainless steel is widely selected for corrosive medium.

The Promass E 200 8E2B25-17M9/0 is widely used in chemical dosing, solvent metering, oil & gas, food and beverage, power plant auxiliary fluid measurement. Promass E200 8E2B series is discontinued by E+H. Most available 8E2B25-17M9/0 units are tested surplus spare parts for metering loop overhaul and emergency replacement. Full order code must be matched before replacement to guarantee material and communication compatibility.
