140DAM59000
Description
140DAM59000
Modicon Quantum Mixed Discrete I/O Module
16 Inputs / 8 Outputs, 115 V AC, 47–63 Hz, Standard Non‑Coating, Fused, No Diagnostic
English Specification Manual (Full Text, No Images)
1. General Description
Inputs: 2 isolated groups × 8 channels
Outputs: 2 groups × 4 solid‑state channels
Manufacturer: Schneider Electric
Series: Modicon Quantum (140 Series)
Module Type: Mixed AC Discrete I/O Module, Standard, Fused, Non‑Diagnostic
Total I/O: 24 points (16 In / 8 Out)
Input Grouping: 2 isolated groups × 8 ch
Output Grouping: 2 groups × 4 ch (solid‑state)
Form Factor: 1 slot, hot‑swappable
Coating: Standard non‑conformal coating
Weight: ~0.45 kg
Key Feature: 16×115V AC In / 8×115V AC Out, 2‑way input isolation, fused outputs, no diagnostic
Application: Factory automation, machinery, assembly lines, general‑purpose 115 V AC signals
2. Electrical Specifications
Inputs (16 × 115 V AC)
Nominal Voltage: 115 V AC
Frequency: 47–63 Hz
Logic 1 (ON): 79–132 V AC
Logic 0 (OFF): 0–20 V AC
Response Time:
OFF → ON: 0.75–4.9 ms
ON → OFF: 7.3–12.3 ms
Isolation: 1780 Vrms, 1 min (channel‑to‑bus)
Input Current: typical 6 mA @ 115 V AC
Absolute Max Input:
200 V AC (1 cycle)
156 V AC (10 s)
132 V AC (continuous)
Outputs (8 × 115 V AC Solid‑State)
Output Type: Solid‑state (triac)
Nominal Voltage: 115 V AC (85–132 V AC operating)
Current Rating:
Per channel: 4 A max
Per group: 8 A max
Per module: 8 A max
Response Time: ≤ 0.5 ms (both directions)
On‑State Voltage Drop: ~1.5 V
Protection: 5 A internal fuse per output group (2 fuses total)
RC Filter: Yes (noise suppression)
Backplane & Power
Backplane Current: 250 mA
Power Dissipation: ~6.0 W max
Internal Power: Powered by Quantum backplane
3. I/O & LED Indicators (Front)
IN0 … IN15 (Green LEDs) – Individual input status (ON = lit)
OUT0 … OUT7 (Green LEDs) – Individual output status (ON = lit)
ACTIVE (Green LED) – Bus communication OK
FUSE (Red LED) – Output fuse blown (per group)
No F‑LED / No Diagnostic LEDs
4. Environmental Specifications
Operating Temperature: 0 °C … +60 °C
Storage Temperature: −40 °C … +85 °C
Relative Humidity: 5% … 95% non‑condensing
Altitude: ≤ 2,000 m (standard); up to 5,000 m derated
ESD: 4 kV contact / 8 kV air
EMI: 10 V/m (80–2000 MHz)
Protection Class: IP20
5. Physical & Mechanical
Dimensions (W × H × D): 35 × 122 × 52 mm (1 slot)
Mounting: Any single slot, hot‑swap compatible
Wiring: Screw terminals (field side)
Input Grouping: 2 isolated groups × 8 ch (1 common per group)
Output Grouping: 2 groups × 4 ch (1 common per group)
Field Wire Size: 0.5 … 2.5 mm²
6. Wiring & Connection
Inputs
Common: 1 common per input group (2 commons total)
Input: Apply 115 V AC between group common and input terminal
Outputs
Common: 1 common per output group (2 commons total)
Output: Switch 115 V AC from common to load
Fuse: Internal 5 A fuse per output group (replaceable via front cover)
Shielding: Recommended for long cables; ground at one end only
7. Software Configuration
Unity Pro (recommended)
Concept v2.2+
ProWORX 32
Add 140DAM59000 (1 slot) to I/O map
Default input address: %I0 … %I15 (1 word)
Default output address: %Q0 … %Q7 (1 word)
Set output filter (optional)
Download to CPU
8. Troubleshooting
All IN LEDs OFF: Check 115 V AC supply and input group common wiring
ACTIVE OFF: Module not recognized; reseat or check backplane
OUT LEDs ON but no load power: Check output common, wiring, or blown group fuse
FUSE LED ON: Replace internal 5 A fuse for affected output group
Erratic Inputs: Poor grounding, noise, or loose terminals
9. Certifications
CE (EN 55011, EN 61131‑2)
UL 508 / CSA C22.2 No. 142
CUL, FM Class I Div 2
RoHS compliant
10. Ordering Information
140DAM59000: Standard non‑coated, Fused / Non‑Diagnostic (general environment)
140DAM59000C: Conformal coated, Fused / Non‑Diagnostic (harsh environment)
