Schneider Electric METSEION92030 Power Meter Product Description

Overview

Schneider Electric METSEION92030 is an ION9200 series high‑performance power and energy meter, designed for multi‑circuit electrical measurement, power quality monitoring and energy management in low‑voltage distribution systems. This Schneider power meter supports direct or CT‑connected three‑phase measurement and rich onboard I/O and communication functions. METSEION92030 is widely used for transformer feeders, main bus monitoring, building energy management and substation auxiliary power cabinets, for new panel build, system upgrade and spare‑part replacement.

Features

Schneider Electric METSEION92030 measures voltage, current, active/reactive/apparent power, power factor, frequency, active/reactive energy, demand and harmonic distortion up to the 63rd order. This Schneider power meter integrates event logging, waveform capture and sag/swell detection for power quality troubleshooting. METSEION92030 is equipped with digital inputs and relay outputs for pulse counting, status acquisition and alarm relay control. The meter supports Modbus TCP, Modbus RTU and ION protocol, enabling data upload to EcoStruxure, SCADA and BMS systems. It supports dual‑source power supply and time synchronization via SNTP for timestamp consistency of records.

Specs

Schneider Electric METSEION92030 power meter

• Brand: Schneider Electric

• Series: ION9200

• Model: METSEION92030

• Measurement: 3‑phase, 4‑wire / 3‑wire

• Voltage input: 100–480 V AC L‑L

• Current input: CT secondary 5 A / 1 A

• Harmonics: Up to 63rd harmonic

• Communication: Modbus TCP, Modbus RTU, ION

• I/O: Digital inputs, relay outputs

• Power supply: 100–240 V AC / 125–250 V DC

• Mounting: 96×96 mm panel cutout

• Standard: IEC 61557‑12, IEC 62053‑22

Principle

Schneider Electric METSEION92030 samples voltage and current signals from PTs and CTs. The internal metering chip calculates electrical parameters, energy accumulation and harmonic components continuously. When power quality events such as voltage sag, swell or over‑limit harmonic are detected, the meter records timestamps and waveform snapshots. Measured values, energy registers and fault records can be read by upper systems via communication ports. Digital outputs can be configured to trigger alarms or pulse output for energy pulse metering.

Applications

Schneider Electric METSEION92030 is deployed in factory main distribution rooms, commercial buildings, data centres, water treatment plants and hospital power systems. This Schneider power meter serves as a high‑accuracy monitoring unit for transformer secondary, bus sections and large important loads. METSEION92030 fits energy management renovation and spare replacement of ION9200 series power meters.

Installation & Maintenance Notes

Follow official Schneider ION9200 hardware manual during installation of METSEION92030. Confirm CT polarity and wiring sequence; wrong polarity will cause power and energy reading errors. Configure CT ratio, PT ratio, communication parameters and alarm thresholds after replacement. Back up meter configuration before replacement. Check wiring terminal tightness and shielding of communication cables periodically. Confirm exact part number METSEION92030 before spare‑part swap‑out to verify I/O allocation and communication feature compatibility.
