Schneider Electric PJF36000S80 Automatic Switch for Galaxy PDU Product Description

Overview

Schneider Electric PJF36000S80 is an automatic switch assembly for the Schneider Galaxy PDU power distribution unit, used in 400–500 kVA high‑capacity power distribution cabinets for data centre and critical industrial power supply. This Schneider Electric automatic switch undertakes main circuit switching and fault isolation inside the Galaxy PDU cabinet, supporting automatic transfer and protection logic for dual‑source power distribution. PJF36000S80 is a dedicated internal switch component matched with Galaxy PDU systems, widely used for cabinet overhaul, system upgrade and spare‑part replacement of existing Galaxy PDU power distribution equipment.

Features

Schneider Electric PJF36000S80 automatic switch is built for high‑current continuous operation inside the PDU enclosure, with robust contact structure and arc extinguishing chamber. This Schneider Electric automatic switch supports interlock logic for dual power paths to prevent parallel connection of two incoming sources. PJF36000S80 integrates status feedback contacts for remote monitoring of switch ON/OFF/trip status by upstream control and SCADA systems. The Schneider Electric automatic switch is designed to coordinate with the PDU controller to execute automatic switching sequences during mains failure or recovery. This Schneider Electric automatic switch complies with IEC and UL standards for critical power infrastructure and is validated for stable operation under high inrush current conditions.

Specs

Schneider Electric PJF36000S80 automatic switch

• Brand: Schneider Electric

• Matching system: Galaxy PDU 400–500 kVA

• Function: Automatic power transfer / main isolation switch

• System voltage: 400V three‑phase AC

• Mounting: Built‑in installation inside Galaxy PDU cabinet

• Control: Linked with PDU master controller for interlock and auto transfer

• Signal: Auxiliary status contacts for remote feedback

• Ambient: Indoor cabinet environment, controlled temperature and humidity

Principle

Schneider Electric PJF36000S80 automatic switch receives logic commands from the Galaxy PDU controller. When the primary incoming power deviates from normal parameters, the controller triggers the switch to disconnect the faulty source and close the standby source after interlock verification. The mechanical interlock mechanism prevents both main and standby contacts from closing simultaneously. The built‑in auxiliary contacts feed switch position back to the PDU controller and upper monitoring system for alarm logging and status display. In short‑circuit or overload events, upstream protective devices clear the fault while PJF36000S80 completes isolation of the faulted feeder.

Applications

Schneider Electric PJF36000S80 automatic switch is mainly deployed in large data centre power rooms, critical industrial power plants and infrastructure power distribution skids equipped with Galaxy PDU. This Schneider Electric automatic switch serves as the core switching component for dual‑input redundant power distribution. PJF36000S80 fits PDU cabinet maintenance, power system renovation and spare replacement of legacy Galaxy PDU switch assemblies. It ensures uninterrupted power supply to critical IT and process loads during single‑source power failure.

Installation & Maintenance Notes

Follow official Schneider Electric Galaxy PDU service manuals during installation of Schneider Electric PJF36000S80 automatic switch. Execute full lockout‑tagout procedures before any work, as this unit belongs to critical uninterruptible power circuits. Verify mechanical interlock function after replacement to eliminate the risk of cross‑source paralleling. Check terminal torque, contact condition and auxiliary signal wiring periodically, especially in high‑load, high‑temperature cabinet environments. Confirm exact part number PJF36000S80 before spare‑part swap‑out to ensure mechanical dimensions, interlock mechanism and PDU controller compatibility. Back up PDU transfer logic parameters before replacement.
