XGEDA CH1160D-1MF Product Description

XGEDA CH1160D-1MF is a professional LCD TV switching power supply board for large-size commercial and monitoring LCD television. This LCD TV switching power supply board accepts 100~240V AC universal input and converts mains power into multiple groups of stable DC voltage for TV mainboard, backlight LED strips and peripheral circuits. The compact LCD TV switching power supply board integrates EMI filter, rectifier circuit and high-frequency transformer on single PCB board. This LCD TV switching power supply board provides continuous power output for image display and backlight driving of TV display equipment.

CH1160D-1MF delivers reliable multi-channel DC power conversion for simultaneous power supply to TV main control board and LED backlight strips. Stable multi-channel DC power conversion automatically adjusts output voltage under load fluctuation. Anti-interference multi-channel DC power conversion suppresses switching ripple to protect TV panel. Dependable multi-channel DC power conversion supports long-time continuous display in monitoring rooms.

This unit features onboard integrated protection circuit including over-current, short-circuit, over-temperature and over-voltage protection. The sensitive onboard integrated protection circuit triggers rapid power cut when electrical faults occur. The high-reliability onboard integrated protection circuit prevents PCB burnout and avoids screen damage. This durable onboard integrated protection circuit simplifies fault diagnosis and spare replacement work.

XGEDA CH1160D-1MF is widely used in industrial monitoring terminals, commercial display screens and large-size LCD TV repair projects. It is compatible with multiple 50/58 inch TV models and equipped with multi-pin plug connectors. It adopts polycarbonate housing and built-in fuse for surge protection. It serves as replacement spare power board for commercial LCD display equipment.
