Detailed Description PCI1500S7 belongs to Applicom PCI1500 series industrial fieldbus adapter card, PCI 2.2 universal short card, single PCI slot, 5V PCI bus power supply. This card focuses on MPI/S7 master communication for Siemens S7-300 / S7-400 PLC, supports MPI up to 187.5kbps, PPI for S7-200 and FDL protocol for old S5 PLC. Different from PCI1500PFB, PCI1500S7 is optimized for S7 MPI communication without full PROFIBUS DP master function. It adopts independent onboard ASPC2 processor and built-in memory, offloads communication task from host PC CPU.

The card is equipped with 9pin D-Sub RS485 galvanically isolated MPI port, two LED indicators for bus activity and fault diagnosis. It uses Applicom PCConf configuration software to set station address, baud rate and data mapping. It supplies OPC server, DDE, ActiveX and DLL development interface, compatible with old SCADA software, LabVIEW and custom Windows applications. Supported operating systems are Windows NT4, Windows 2000, Windows XP.

IP20 protection grade, installed inside industrial PC chassis, operating temperature range 0~60℃.

PCI1500S7 is discontinued legacy Applicom spare part. Many old industrial monitoring PCs still use this MPI card. When the original card fails, replacing it with identical PCI1500S7 can reuse existing PCI slot industrial PC, MPI cable, station address configuration and original SCADA/OPC project. Technicians install PCI card, run PCConf tool, set MPI parameters and verify PLC data read/write, so the PC monitoring system resumes operation and reduces downtime.

Before shipment, every PCI1500S7 undergoes comprehensive functional inspection including power-on self-test, PCI bus initialization test, MPI bus communication test, LED status check and OPC data read-write test. All products come with 12-month warranty. Our automation technical team provides remote support for hardware installation, PCConf configuration and MPI communication fault diagnosis. Fast global shipping available for urgent maintenance orders.

For automation maintenance engineers and system integrators, PCI1500S7 is reliable spare PCI MPI/S7 communication card for legacy Applicom industrial PC monitoring systems. It restores data acquisition between IPC and Siemens S7 PLC, extends service life of old automation assets and avoids high-cost whole industrial PC renovation.
