Detailed Description XBTGT5330 is high-performance Magelis XBTGT series industrial touch panel for cabinet flush mounting. It adopts 10.4-inch TFT color LCD, 65536 colors, VGA 640×480 resolution, analog resistive touch screen. Power supply DC24V (19.2~28.8V), max power consumption 30W. 266MHz RISC processor, 32MB flash memory for HMI project storage, 512KB battery-backed SRAM to retain recipe, alarm logs and RTC clock data after power off.

This HMI integrates 10/100Mbps Ethernet RJ45 port, COM1 RS232 and COM2 RS485 serial ports, CompactFlash card slot (max 1GB) for data logging and program backup. It supports optional fieldbus expansion card including Profibus-DP and DeviceNet. It supports Modbus TCP, Modbus RTU, Uni-TE, Mitsubishi, Omron, Allen‑Bradley, Siemens and other mainstream PLC protocols. Project configuration and download use Vijeo Designer software. It supports real-time data display, parameter input, alarm log, trend curve, recipe management, multi-language switching and web remote monitoring. Front panel IP65 dustproof and waterproof, rear IP20. Green/orange LED indicator shows power and backlight fault status for quick on-site troubleshooting.

Operating temperature range 0~50℃, cutout dimension 259×201mm, overall dimension 270.5×212.5×57mm. CFL backlight with service life 50000 hours.

XBTGT5330 is discontinued legacy Schneider HMI spare part. Many old automation production lines still use XBTGT touch panel. When the original unit fails, replacing it with identical XBTGT5330 can reuse existing panel cutout, wiring and original Vijeo Designer project without redevelopment. Technicians install the touch panel, download screen program and verify PLC/network communication, so the HMI operation system resumes operation and reduces downtime.

Before shipment, every XBTGT5330 undergoes comprehensive functional inspection including power-on self-test, touch calibration, TFT display test, serial & Ethernet communication verification, CF card read-write test and battery health check. All products come with 12-month warranty. Our automation technical team provides remote support for project backup, screen download, wiring guidance and communication fault diagnosis. Fast global shipping available for urgent maintenance orders.

For automation maintenance engineers and system integrators, XBTGT5330 is reliable spare TFT touch terminal for legacy Schneider Magelis XBTGT control systems. It restores local machine operation and data monitoring functions, extends service life of automation assets and avoids high-cost whole control system renovation.
