Detailed Description PC1500PFB is an old ISA bus PROFIBUS master interface card manufactured by Applicom (later acquired by Woodhead / Molex). It is designed for legacy industrial PC with ISA slot, used to connect PC to PROFIBUS fieldbus network, acting as PROFIBUS DP master to exchange real-time data with Siemens S7 PLC and other PROFIBUS slave devices. Onboard dedicated i960 processor handles fieldbus communication independently, reducing host CPU load. Max baud rate 1.5Mbps, supports PROFIBUS DP, FDL, S7 protocol, PPI/PPI+. It provides OPC server, DDE, ActiveX and DLL interface for SCADA, LabVIEW, HMI upper software data access. Widely applied in old chemical, metallurgy, packaging continuous production line PC monitoring stations.

This card uses ISA bus, requires IRQ and DPRAM memory address configuration via setup tool PCConf. PROFIBUS terminal port with bus termination resistor. Onboard LED indicators show power, bus activity and communication fault for fast on-site troubleshooting. Supports multiple cards installed in one industrial PC, assign unique board ID for multi-channel PROFIBUS network. Compatible with old Windows OS: Windows NT4, Windows 2000, Windows XP.

IP20 protection grade, operating temperature range 0~60℃, installed inside industrial PC chassis.

PC1500PFB is discontinued legacy Applicom spare part. Many old industrial control PC still run with this ISA PROFIBUS card. When the original card fails, replacing it with identical PC1500PFB can reuse existing ISA slot industrial PC, PROFIBUS cable, GSD configuration and original SCADA/OPC project. Technicians install the ISA card, set IRQ and memory address, configure PCConf software and verify PROFIBUS communication, so the PC monitoring system resumes operation and reduces downtime.

Before shipment, every PC1500PFB undergoes comprehensive functional inspection including power-on self-test, ISA bus initialization test, PROFIBUS bus communication test, LED status check and OPC data read-write test. All products come with 12-month warranty. Our automation technical team provides remote support for hardware installation, PCConf configuration and communication fault diagnosis. Fast global shipping is available for urgent maintenance orders.

For automation maintenance engineers and system integrators, PC1500PFB is reliable spare ISA PROFIBUS master card for legacy Applicom industrial PC monitoring systems. It restores PROFIBUS fieldbus data collection and upper computer monitoring functions, extends service life of old automation assets and avoids high-cost whole industrial PC system renovation.
