XBTF032110 Schneider Magelis XBTF 5.7" Color Keypad HMI Operator Terminal
XBTF032110 is Schneider Magelis XBTF series 5.7-inch color graphic operator terminal, originally released under Telemecanique brand, designed for on-site machine operation and process visualization. It adopts 320×240 STN color display with physical function keypad array, powered by 24VDC with 35W power consumption. The front panel reaches IP65 protection grade against dust and splash water, suitable for embedded cabinet mounting in dusty, oil mist workshop environments. The built-in flash memory stores HMI project files, recipe parameters and historical alarm logs for local data retention.
This graphic terminal is equipped with RS232 and RS485 serial communication ports, supporting Uni-Telway, Modbus and other mainstream protocols to communicate with Schneider PLC, inverters and field sensors. Operators can use the integrated physical keys to complete real-time data viewing, parameter modification, alarm acknowledgement and manual machine operation. The keypad design delivers reliable operation under glove wearing conditions, avoiding the malfunction risks of touch screens in heavy industrial environments. Multi-language display function is supported to satisfy multi-national production site requirements. The terminal is programmed with dedicated XBTL design software, widely used in early automation projects.
XBTF032110 is a fully discontinued legacy automation spare part. It is widely deployed on packaging machinery, textile equipment, small process control systems and assembly lines. When the original HMI fails, replacing it with identical XBTF032110 can directly load the original HMI project without screen reprogramming or cabinet cutout modification. The original wiring layout and control system architecture remain unchanged, operators can continue familiar keypad operation without retraining. This replacement greatly cuts maintenance cost and shortens production downtime, avoiding large-scale control system renovation.
We supply fully tested XBTF032110 spare panels. Before shipment, each unit undergoes comprehensive functional inspection, including power-on boot test, display brightness and color inspection, keypad response test, serial communication verification and project upload/download test. We check memory read-write stability and front panel sealing condition to guarantee reliable hardware performance. All products come with 12-month warranty. Our automation technical team provides remote support for project backup, wiring guidance, communication parameter configuration and fault diagnosis. Fast global shipping is available for urgent maintenance orders.
For automation maintenance engineers and system integrators, XBTF032110 is a reliable spare keypad HMI for legacy Magelis XBTF control systems. The physical keypad structure provides superior stability in harsh workshop environments. It helps maintain continuous operation of aging production equipment, extends service life of existing automation assets and prevents expensive full HMI system upgrade.
