1. General Information

• Part Number: 3408KP

• Manufacturer: XYCOM Automation (Schneider Electric / Pro‑face)

• Product Type: 7.7” Industrial Flat Panel PC with Keypad (HMI/IPC)

• Series: 3400 Series

• Status: Discontinued (EOL); refurbished/used available

• Weight: ~4.1 kg (9.0 lbs)

• Mounting: Panel mount

2. Display

• Size: 7.7” Color TFT LCD

• Resolution: 640 × 480 (VGA)

• Brightness: Standard industrial grade

• Backlight: CCFL, long life

• Touchscreen: None (keypad‑only model)

3. Keypad

• Type: 51‑position reprogrammable function/alpha keypad

• Keys: 20 function/alpha keys, control keys, numeric & cursor keys

• Legends: 6 keys relegendable; custom inserts supported

4. System Hardware

• CPU: AMD 5x86 133 MHz

• Memory: Up to 64 MB EDO DRAM (72‑pin SIMM)

• Storage: 6.0 GB+ IDE HDD, floppy option, CompactFlash support

• Graphics: PCI video controller, 1 MB VRAM

• Expansion: PC/104 (up to 2 stacked cards)

5. Power Supply

• Input Voltage: 90–250 VAC, 50/60 Hz, autosensing; 18–36 VDC (24 V nominal)

• Power Consumption: 40 W max

• Protection: Overvoltage, overcurrent, surge

6. I/O Ports

• Serial: 1×RS‑232, 1×RS‑232/485

• Parallel: 1×SPP/EPP

• Ethernet: 1×10/100 Mbps (RJ45)

• PS/2: Keyboard/mouse

• Infrared: IrDA‑compatible

• Audio: Line in/out, mic

7. Mechanical Specifications

• Front Panel (W×H): 305 × 229 mm (12.0” × 9.0”)

• Depth: 107 mm (4.20”); 84 mm (3.3”) behind panel

• Front Panel Rating: NEMA 4/4X/12, IP65

• Housing: Rugged metal, industrial grade

8. Environmental Ratings

• Operating Temperature: 0 °C to +50 °C

• Storage Temperature: −20 °C to +60 °C

• Humidity: 10%–90% RH, non‑condensing

• Vibration/Shock: IEC 60068 compliant

9. Software & OS

• Preloaded OS: MS‑DOS, Windows 95/98/NT

• Compatible OS: Windows 2000, QNX, VxWorks

10. Certifications

• Safety: UL 508, CE; UL Class I Div 2, Class II Div 2

• EMC: FCC Class A, CE EN 61000‑6‑2/4

11. Availability & Replacement

• Original New: Discontinued

• Supply: Tested refurbished, used spares

• Recommended Replacement: Pro‑face GP4000/GP5000 series 7–8” industrial keypad/touch panel
