1. General Information

• Part Number: 3400T

• Manufacturer: XYCOM Automation (Schneider Electric / Pro‑face)

• Product Type: 15” Industrial Flat Panel Workstation (HMI/IPC)

• Series: 3400 Series

• Status: Discontinued (EOL); refurbished/used available

• Weight: ~5.4 kg (12 lb)

• Mounting: Panel mount, VESA mount

2. Display

• Size: 15” Color TFT LCD

• Resolution: 1024 × 768 (XGA)

• Brightness: 250 cd/m² typical

• Backlight: CCFL, long life

• Touchscreen: Analog resistive, sealed

3. System Hardware

• CPU: Intel Celeron / Pentium III (Socket 370)

• Memory: Up to 512 MB SDRAM

• Storage: IDE HDD, CompactFlash Type II support

• Graphics: Integrated VGA, up to XGA

4. Power Supply

• Input Voltage: 100–240 VAC, 50/60 Hz

• Type: Internal wide‑range switching PSU

• Protection: Overvoltage, overcurrent, surge

5. I/O Ports

• Serial: 2 × RS‑232, 1 × RS‑232/422/485

• Parallel: 1 × SPP/EPP/ECP

• USB: 2 × USB 1.1

• Ethernet: 1 × 10/100 Mbps (RJ45)

• PS/2: Keyboard/mouse

• Audio: Line in/out, mic

6. Mechanical Specifications

• Dimensions (W×H×D): 410 × 310 × 95 mm (approx)

• Front Panel Rating: NEMA 4/4X/12, IP65

• Housing: Rugged metal, industrial grade

7. Environmental Ratings

• Operating Temperature: 0 °C to +50 °C

• Storage Temperature: −20 °C to +60 °C

• Humidity: 10%–90% RH, non‑condensing

• Vibration/Shock: IEC 60068 compliant

8. Software & OS

• Compatible OS: Windows 2000/XP, DOS, QNX, VxWorks

9. Certifications

• Safety: UL 508, CE

• EMC: FCC Class A, CE EN 61000‑6‑2/4

10. Availability & Replacement

• Original New: Discontinued

• Supply: Tested refurbished, used spares

• Recommended Replacement: Pro‑face GP5000 series 15” touch panel
