1. General Information

• Part Number: 3015T

• Manufacturer: XYCOM Automation (Schneider Electric / Pro‑face)

• Product Type: 15" Industrial Touch Panel PC / Integrated HMI (T = Touchscreen)

• Series: 3015 Series Rack‑Mount Industrial Computer

• Status: EOL Discontinued; Refurbished/Spare Available

• Weight: ~6.8 kg (15 lbs)

2. Product Description

3. Hardware Specifications

Display

• Screen: 15" Color TFT LCD

• Resolution: 1024×768 XGA

• Brightness: 350 cd/m²

• Contrast: 400:1

• Touch: 5‑Wire Resistive Touchscreen, RS‑232 / USB interface

Electrical

• Input: 100–240 VAC 50/60 Hz wide voltage

• Optional: 18–30 VDC 24V nominal DC power supply

• Protection: Overvoltage, Overcurrent, Surge, EMI Filtering

I/O Interfaces

• Video: VGA DB15

• Serial: Multi-channel RS‑232/485 DB9

• Ethernet: 10/100 Mbps RJ45

• USB: Front & Rear USB ports

• PS/2 Keyboard & Mouse

Mechanical & Environmental

• Dimensions: 482.6 × 367.2 × 101.6 mm (19.0 × 14.5 × 4.0 in)

• Mounting: Standard 19" Rack Panel Mount

• Front Seal: NEMA 4/4X/12, IP65

• Operating Temp: 0～+55 °C

• Storage Temp: −40～+85 °C

• Humidity: 10%–90% Non‑Condensing

• Hazardous: UL Class I Div 2 Certified

• Certifications: CE, FCC Class A, UL 508

4. Compatibility

• Host: XYCOM 2000T、2050T、2225-0036、278229-P、VME Motion System

• OS: Windows 2000/XP、DOS、QNX、VxWorks

• Driver: Special XYCOM touch & motion matching driver

5. Availability

• Original new: Discontinued

• Supply: Refurbished tested units, spare parts

• Replacement: Pro-face PS5000 series integrated industrial HMI
