1. General Information

• Part Number: 2225-0036

• Manufacturer: XYCOM Automation (Schneider Electric / Pro‑face)

• Product Type: Industrial Panel‑Mount Workstation / HMI

• Series: 2225 Series (legacy industrial PC platform)

• Status: EOL (Discontinued; available as refurbished/used)

• Weight: Approx. 22 kg (48.5 lbs)

2. Product Description

3. Hardware Specifications

Display & User Interface

• Display: 15” Industrial Color LCD, high brightness (800 cd/m²)

• Resolution: 1024 × 768 (XGA)

• Touchscreen: 5‑wire resistive, NEMA 4/4X sealed

• Keyboard: Integrated 88‑key industrial membrane keyboard

• Pointing Device: Industrial trackball (standard)

System & Processor

• CPU: Intel Pentium III (800 MHz standard, up to 1.0 GHz)

• Chipset: Industrial ATX core logic

• Memory: 256 MB SDRAM (standard), max 512 MB

• Storage: 40 GB IDE HDD (removable); supports CompactFlash (CF) up to 512 MB

• Expansion: 4× slots (1 PCI, 1 ISA, 1 PCI/ISA shared, 1 half‑length PCI)

I/O Ports

• Ethernet: 1× 10/100 BaseT RJ45

• Serial: 4× RS‑232/422/485 (COM1–COM4, DB9)

• USB: 2× USB 1.1 (1 front, 1 rear)

• Parallel: 1× LPT (DB25, printer)

• Video: VGA (DB15, external monitor)

• PS/2: Keyboard & mouse ports

• Audio: Line in/out, mic in

Power Supply

• Input: 100–132/200–240 VAC, 50/60 Hz (switchable)

• Max Current: 4.0 A @ 110 VAC

• Protection: Overvoltage, overcurrent, surge, short‑circuit, EMI filtering

4. Mechanical & Environmental

• Dimensions: 483 × 400 × 150 mm (19.0 × 15.7 × 5.9 in)

• Mounting: Panel mount, 19” rack mount compatible

• Protection: NEMA 4/4X/12, IP65 (front panel sealed)

• Operating Temp: 0 °C to +55 °C

• Storage Temp: −40 °C to +85 °C

• Humidity: 10%–90% non‑condensing

• Vibration: 0.2 g (5–2000 Hz, operating)

• Shock: 5.0 g peak (operating)

• Certifications: CE, FCC Class A, UL 508, hazardous location rated (Class I Div 2)

5. Compatibility

• OS Support: Windows 2000/XP, DOS, QNX, VxWorks

• Protocols: Modbus RTU/TCP, Profibus‑DP, Ethernet/IP, TCP/IP

• System Integration: Compatible with XYCOM 2000/2225 series peripherals and VMEbus systems

6. Installation & Maintenance

1. Mounting: Install in industrial panel/rack with proper chassis grounding.

2. Cabling: Separate power and signal cables (≥10 cm) to reduce EMI.

3. Cooling: Maintain unobstructed airflow; avoid high‑temperature zones.

4. Handling: ESD protection required; avoid harsh chemicals on front panel.

5. Maintenance: Clean touchscreen/keypad monthly; inspect cables quarterly; replace HDD every 3–5 years.

7. Availability

• Original: Discontinued by Schneider Electric.

• Spare Parts: Refurbished, tested units and used surplus available.

• Replacement: Succeeded by Pro‑face PS/5000 series industrial HMIs and panel PCs.
