General Information

• Model: 9987 (Portrait PC / Flat‑panel Industrial Computer)

• Manufacturer: XYCOM Automation

• Type: Panel‑mount industrial HMI/IPC (open architecture, PC/AT compatible)

• Status: EOL; available as refurbished/used

• Nickname: Portrait PC

Mechanical

• Form Factor: Panel‑mount industrial workstation

• Mounting Depth: 5.62 in (142.7 mm)

• Backplane: 4‑slot full‑length passive ISA backplane

• Enclosure: Industrial steel; front panel NEMA 4/4X/12, IP65 (sealed)

• Drawer: Slide‑out for easy access to drives, backplane, power supply

Display & Keypad

• Display: 10.4 in 256‑color CCFT TFT LCD

• Resolution: 640×480 (VGA)

• Keypad: 32 data entry keys + 10 function keys (sealed membrane)

System Hardware

• CPU: 486/Pentium‑class single‑board industrial processor

• Memory: Standard up to 256 MB DRAM (max 512 MB)XYCOM

• Storage:

  • 3.5‑in 1.44 MB floppy drive (front/rear access)

  • Optional IDE hard disk

• OS Support: MS‑DOS, Windows NT, Windows 2000/XPXYCOM

Communication & I/O

• Serial: 2× RS‑232 (COM1/COM2)

• Parallel: Standard printer port

• PS/2: Keyboard & mouse portsXYCOM

• USB: 1.1 compliant ports (later revisions)XYCOM

• Ethernet: Optional 10/100 BaseTXYCOM

Electrical

• Power Supply: 110 W

• Input Voltage: 90–250 VAC, 47–63 Hz, 2.1 A max

• Isolation: Industrial surge/noise filtering; CE/FCC Class A

Environmental

• Operating Temp: 0 °C to +50 °C

• Storage Temp: −40 °C to +85 °C

• Humidity: 10%–90% non‑condensing

• Shock/Vibration: Industrial‑grade (IEC 60068 compliant)

Key Features

• Open architecture: Accepts IBM PC/AT‑compatible ISA cards

• All‑in‑one design: Integrates CPU, display, keypad, storage, I/O

• Rugged for factory floor and harsh environments

Applications

• Factory automation & process control

• Production line HMI/operator interface

• Legacy PLC/DCS monitoring & data acquisition

• Industrial machinery, power, petrochemical, and food/beverage industries
