General Information

• Model: 9960 (also known as Huskey Operator Panel)

• Manufacturer: XYCOM Automation (later Schneider Electric)

• Type: Panel-mount industrial HMI / operator interface with integrated display and keypad

• Status: Discontinued (EOL); available only as refurbished/used units

• Weight: Approx. 30 lb (13.6 kg)

Electrical

• Power Input: 100–250 VAC, 50/60 Hz, 2.3 A max

• Isolation: Industrial surge & noise filtering; meets CE/FCC Class A

Display & Keypad

• Display: 10.4-inch color TFT LCD

• Resolution: 640×480 (VGA)

• Touchscreen: 5-wire resistive (optional)

• Keypad: Sealed industrial membrane, 24 function keys + 12 numeric keys, relegendable

• Front Panel: NEMA 4/4X/12, IP65 (dust/water resistant)

System Hardware

• CPU: Intel Pentium-class industrial processor

• Memory: 64MB DRAM (expandable)

• Storage: 2.5-inch IDE hard disk (up to 10GB)

• OS Support: Windows 95, Windows NT 4.0, MS-DOS

Communication Interfaces

• Serial: 2× RS-232/485 switchable

• Parallel: Standard printer port

• Ethernet: Optional 10/100 Mbps

• Peripherals: PS/2 keyboard & mouse

Environmental

• Operating Temp: −10°C to +50°C

• Storage Temp: −40°C to +60°C

• Humidity: 10%–90% non-condensing

• Shock/Vibration: Industrial-grade, compliant with IEC 60068

Applications

• Factory automation, production line control

• Legacy PLC/DCS system monitoring

• Machinery, chemical, power, and harsh industrial environments
