1. General Information

• Model: 9450

• Manufacturer: XYCOM Automation (Pro‑face)

• Type: Industrial Panel PC / AT‑Compatible Industrial Control Computer

• Mounting: Panel mount / 19-inch EIA rack mount

• Front Protection: NEMA 4/4X/12, IP65 dust & water sealed

• Enclosure: Heavy-duty steel, impact-resistant CRT protective cover

• Weight: 27.2 kg (60 lbs)

• Status: Discontinued legacy device, refurbished/spare parts only

• Structure: Slide-out modular main unit, easy maintenance

2. Electrical Parameters

• Input Voltage: 115 / 230 VAC auto-switch

• Frequency: 50 / 60 Hz

• Rated Current: 3.3 A @ 115V

• Rated Power: 200 W, derated to 150 W

• Power Supply: Industrial isolated PSU, surge & anti-EMI protected

• Backplane: 7-slot PC/AT passive backplane, 5 usable ISA slots

3. Display & Operation

• Display: Original 14-inch color CRT SVGA

• Resolution: 640×480 / 800×600 / 1024×768

• Keypad: Built-in industrial sealed keypad (32 data keys + 20 function keys)

• Touch: Optional 5-wire resistive industrial touchscreen

• Storage: IDE mechanical hard disk + front-access 1.44MB floppy drive

4. System Hardware

• CPU: Intel Pentium III / Celeron up to 433 MHz

• Memory: Standard 256 MB DRAM, max expandable 256 MB

• Video: Integrated AGP graphics, 4 MB video RAM

• Expansion: 5 ISA slots (full-length / medium / short mixed)

• Compatible OS: DOS, Windows 2000 / XP

5. External Interfaces

• Serial: RS‑232 ×2, support RS‑485 conversion

• Parallel: DB25 printer parallel port

• Ethernet: Onboard 10/100 Base-T LAN

• PS/2: Keyboard & mouse interface

• VGA: External extended display output

6. Environmental Conditions

• Operating Temperature: 0 ℃ ~ +50 ℃

• Storage Temperature: -40 ℃ ~ +60 ℃

• Humidity: 20% ~ 80% RH, non-condensing

• Compliance: Industrial vibration & shock resistant, UL / CE / FCC certified
