1. General Description

2. Electrical Specifications

• Input Voltage: 115 / 230 VAC Auto-Switching, 50/60 Hz

• Rated Current: 0.32 A @ 115VAC; 0.16 A @ 230VAC

• Maximum Power Consumption: ≤ 75 W

• Power Protection: Built-in industrial power supply, surge protection & ESD electrostatic protection

3. Display & Human Interface

• Display: 12-inch Color Industrial CRT Monitor

• Native Resolution: SVGA 800 × 600

• Touch Screen: Digital Resistive Touch (High precision, oil & dust resistant, better than analog touch of 4850)

• Keypad: Industrial Dustproof Membrane Keypad, durable for harsh workshop environments

• Continuous Operation: 24-hour long-time stable operation

4. System Hardware Configuration

• CPU: Intel Pentium III, up to 1.26GHz

• System Memory: 256 MB standard, expandable up to 512 MB DRAM

• Storage: Removable 20 GB IDE Hard Disk; Optional CompactFlash up to 512 MB

• Drive: Floppy Disk Drive + Optional CD-ROM / CD-RW / DVD

• Expansion Slots: 4 slots total (1 PCI + 1 ISA + flexible ISA/PCI + half-length PCI DOC socket)XYCOM

5. Communication Interfaces

• Serial Ports: RS-232, RS-422, RS-485 multi-channel industrial communication

• Parallel Port: Standard Printer Parallel Interface

• Peripheral Ports: PS/2 Keyboard & Mouse, USB 1.1 × 2

• Network Port: 10/100 Base-T Ethernet

• Extended Interface: External drive bay expansion for industrial signal expansionXYCOM

6. Environmental Parameters

• Operating Temperature: 0 °C ~ +50 °C

• Storage Temperature: -20 °C ~ +60 °C

• Humidity: 20% ~ 80% RH, Non-condensing

• Mechanical Performance: Industrial grade anti-vibration & anti-shock, compliant with EN 61131-2 standard

• Hazardous Location Certification: Class I Div 2, Groups A-D; Temperature Code T5XYCOM

7. Compliance & Certification

• CE, UL, cUL, FCC Class A Certified

• Meet European industrial safety and electromagnetic compatibility standards

8. Application
