General

• Model: 4810ERO (Touch Panel PC)

• Mfr: Pro‑face (XYCOM Automation)

• Type: 15” Industrial Panel PC / HMI

• Mounting: Panel mount

• Front Panel: NEMA 4/4X/12, IP65

• Weight: ~8 kg (17.6 lbs)

Electrical

• Input: 100–240 VAC, 50/60 Hz, autosensing

• Power: 250 W internal PSU

Display & Touch

• Display: 15” TFT LCD, XGA 1024×768

• Brightness: 300 cd/m²

• Touch: Analog resistive (glove‑friendly)

System

• CPU: Intel Core i7‑8700T (6‑core, 3.2 GHz / 4.6 GHz turbo)

• Memory: 16 GB DDR4 (max 64 GB)

• Storage: 256 GB SSD (expandable HDD)

• OS: Windows 10 Professional

I/O Interfaces

• USB: 4×USB 3.0, 2×USB 2.0

• Serial: 2×RS‑232/485

• Ethernet: 2×Gigabit Ethernet

• Video: VGA, HDMI

• Audio: Line in/out, mic

Environmental

• Operating Temp: 0 °C to +50 °C

• Storage Temp: −20 °C to +60 °C

• Humidity: 20%–80% RH, non‑condensing

Mechanical (W×H×D)

• Dimensions: 400 × 300 × 130 mm

• Panel Cutout: ~385 × 285 mm

XYCOM 4810E (Legacy Operator Terminal)

General

• Model: 4810E (OIT / HMI)

• Type: 12” CRT Operator Terminal

• Mounting: Panel / cabinet mount

• Protection: Front IP20

• Weight: ~9.1 kg (20 lbs)

Electrical

• Input: 115/230 VAC, 50/60 Hz, 0.32 A

• Power: ~37 W max

Display & Input

• Display: 12” CRT, 800×600 SVGA

• Keypad: 48‑key industrial keypad

• Touch: Optional resistive touch

I/O & Expansion

• Serial: 2×RS‑232

• Parallel: 1×DB25

• Expansion: VMEbus, digital/analog I/O modules

Environmental

• Operating Temp: −20 °C to +60 °C

• Humidity: 5%–95% RH, non‑condensing
