IC101
1. General Information
Model: IC101
Manufacturer: KEBA (Austria)
Type: Industrial central control unit / PLC module
Application: Injection molding machines, machine tools, automated production lines, motion control systems
Mounting: Standard cabinet rail / rack mounting
Protection Class: IP20
Weight: ~0.8 kg
Warranty: 12 months (new/refurbished available)
2. Electrical & Core Specifications
Power Supply: DC 24V (19.2–30V DC, EN 61131-2)
Processor: High-performance industrial CPU (ARM-based)
Memory: On-board RAM/Flash for program & data storage
Real-Time Clock: Battery-backed (for data retention)
3. I/O & Interfaces
Digital I/O: Integrated high-speed inputs/outputs for sensors/actuators
Analog I/O: 0–10V / 4–20mA for process signals
Communication Ports:
Ethernet (TCP/IP, EtherCAT optional)
CANopen / Profibus DP (fieldbus)
Serial (RS-232/485) for HMI/debug
Expansion Slots: For KEBA I/O modules (e.g., FB201, HRS series)
4. Control & Performance
Control Modes: Sequential logic, motion control, PID regulation
Motion Functions: Positioning, synchronization, servo drive control (compatible with HRS10102/HRS201)
Programming: KEBA KeStudio / KeControl environment (IEC 61131-3 compliant)
Scan Time: Fast cycle time for real-time applications
5. Environmental Conditions
Operating Temp: 0°C ~ +55°C
Storage Temp: -20°C ~ +70°C
Humidity: 5%–95% RH, non-condensing
Vibration/Shock: Compliant with EN 61131-2 (industrial grade)
6. Key Features
System Core: Manages entire machine logic, motion, and I/O coordination
Drive Compatibility: Works with KEBA HRS series drives (HRS10102/HRS201) & FB201 I/O module
Safety: Built-in safety functions (overload, overtemp, emergency stop)
Diagnostics: LED status indicators, fault logging, remote monitoring
Compact & Rugged: Industrial design for harsh factory environments
7. Installation & Safety
Install only with power disconnected; use ESD protectionKEBA
Mount on DIN rail; allow 50mm clearance for cooling
Separate high-voltage power cables from low-voltage signal wiresKEBA
Qualified personnel only for wiring, programming & commissioningKEBA
