10F5M3DLBDA

1. General Information

• Part Number: 10F5M3DLBDA

• Manufacturer: KEB COMBIVERT

• Series: F5 MULTI (Modular High-Performance Drive)

• Type: 3‑Phase Frequency Inverter / Servo Drive

• Application: Machine tools, packaging, material handling, conveyor systems, general automation

• Motor Compatibility: Asynchronous (AC induction), synchronous (SMPM/IPM), high‑speed motors

2. Electrical Ratings (Input)

• Input Voltage: 3 × 305–500 VAC (400 V nominal)

• Input Frequency: 50 / 60 Hz ±5%

• Rated Input Current: 8.1 A (at 400 V)

• Max. Short‑Term Current: 18 A (60 s)

• Mains Fuse (Inert): 16 A max.

3. Electrical Ratings (Output)

• Output Voltage: 3 × 0–Uₗₙ (0–500 VAC)

• Output Frequency: 0–599 Hz (standard); 0–1600 Hz (high‑speed)

• Rated Output Power: 4.0 kVA / 2.2 kW (400 V, 50/60 Hz)

• Rated Output Current: 5.8 A (400 V)

• Switching Frequency: 8 kHz (default); 16 kHz max.

• Overload Capacity: 150% for 60 s; 200% for 30 s

4. Control & Interfaces

• Control Modes: V/F, Sensorless Vector, Flux Vector, Servo (position/speed/torque)

• Feedback: TTL/HTL encoder, resolver, Sin/Cos, SSI, EnDAT 2.1/2.2, BiSS, Hiperface

• Communication: RS‑232/485, Modbus RTU, CANopen, Profibus, Ethernet (optional)

• Digital Inputs: 6 × programmable (PNP/NPN, 24 VDC)

• Digital Outputs: 2 × relay (250 VAC / 5 A) + 2 × transistor (24 VDC / 0.5 A)

• Analog Input: 0–10 V / 4–20 mA (11‑bit)

• Analog Output: 0–10 V / 4–20 mA (programmable)

5. Environmental & Mechanical

• Operating Temperature: 0 °C to +55 °C

• Storage Temperature: -40 °C to +85 °C

• Humidity: 5–95% RH (non‑condensing)

• Protection Class: IP20 (front), IP00 (rear)

• Vibration: 10–100 Hz, 0.1 mm (MIL‑STD‑810)

• Mounting: DIN rail or panel mount

• Dimensions (W×H×D): 120 × 200 × 85 mm

• Weight: ~3.15 kg

6. Safety & Compliance

• Safety Functions: STO (Safe Torque Off, SIL3), overvoltage/undervoltage, overcurrent, short circuit, overtemperature, ESD protection

• Certifications: CE, RoHS, UL, cUL

• Standards: EN 61800‑3 (EMC), EN 50178 (safety), IEC 61131‑2

7. Features

• Integrated braking transistor

• Motor temperature monitoring (KTY/PTC/PT1000)

• 32‑bit internal positioning (32‑bit register)

• Multi‑language LCD keypad (optional)

• Parameter backup/restore via keypad or software
