V4555724-0100 Product Specification

1. Product Overview

2. Core Functions

1. Closed-Loop Control

   High-performance CPU supports position, speed, and current loop control for turbines, valves, and servo motors.

2. Multi-Channel I/O

   Integrated digital and analog I/O with 24V DC isolated signal acquisition.

3. High-Speed Communication

   RJ45 Ethernet (Modbus/TCP) and RS485 for real-time DCS/host interaction.

4. Safety & Protection

   Hardware overcurrent, overload, thermal, short-circuit protection; SIL 2 safety logic for ESD.

5. Diagnostics & Monitoring

   Real-time self-test, channel status, fault logging (wire break, over-range, communication error).

6. Redundancy

   Hot standby redundancy with <100ms failover.



7.

3. Technical Specifications

3.1 Electrical & Performance

• CPU: 32-bit industrial high-performance controller

• I/O Interfaces

  • Digital: 16-ch DI / 16-ch DO (24V DC, isolated)

  • Analog: 8-ch AI (4–20mA / 0–10V), 4-ch AO (4–20mA)

• Communication: 1×RJ45 (10/100Mbps, Modbus TCP), 1×RS485

• Control Cycle: Min 1ms (servo), typical 5–10ms (process)

• Power Supply: 24V DC (±10%), redundant optional

• Power Consumption: ≤25W

• Output Rating: 2A per channel

3.2 Physical & Environmental

• Dimensions: 482.6 × 254 × 133.4mm (19" rack)

• Weight: Approx. 3.45kg

• Mounting: 19" rack card type

• Protection: IP20 (cabinet)

• Operating Temp: -10°C to +60°C

• Storage Temp: -40°C to +85°C

• Humidity: 5%–95%RH (non-condensing)

• Vibration/EMC: IEC 60068-2-6, IEC 61000-4 compliant

3.3 Reliability & Certification

• MTBF: ≥120,000 hours

• Safety: IEC 61508 SIL 2

• Certifications: CE, UL, RoHS

4. Features

• Industrial Reliability: Military-grade components, multi-layer PCB, full isolation.

• Servo-Grade Precision: Microsecond response, control error <0.1%.

• Hot-Swappable: Plug-and-play, auto-identification, online configuration.

• EMI Resistant: Full isolation, multi-stage filtering for power/substation environments.

• Multi-System Compatible: T3000, TXP, MARK VIe, third-party DCS.

5. Applications

• Power: Gas/steam turbine control, boiler valve actuation, generator excitation

• Oil & Gas: Pipeline valves, pumps, reactors, ESD systems

• Rail Transit: Traction control, switch drive, signaling interlocking

• Metals/Paper: Drives, tension control, large equipment servo

6. Ordering Information

• Model: V4555724-0100 (SIRE-S3-1)

• Packaging: Anti-static bag + shockproof carton

• Warranty: 12 months (new original)

• Lead Time: 1–3 days (stock), 15–30 days (custom)
