PENTAIR POOL PUMP LCD DISPLAY SCREEN KEYPAD 3.0HP 3.95 SFHP

PENTAIR LCD DISPLAY SCREEN KEYPAD is the operator control interface assembly for Pentair IntelliProXF variable speed swimming pool pump, rated 3.0HP nominal, 3.95 SFHP (Service Factor Horsepower), 230V single-phase permanent magnet motor. The lcd display screen keypad integrates LCD screen and membrane push-button keypad, mounted directly on the pump drive housing. The lcd display screen keypad displays real-time pump operating data including running RPM, power consumption, runtime counters, fault codes and flow status. The lcd display screen keypad allows field operators to configure up to 8 independent programmable speed schedules, set timer cycles, activate quick-clean mode and lock parameters with password protection. The lcd display screen keypad communicates with the pump internal drive controller via onboard serial bus, and supports RS485 link to Pentair ScreenLogic pool automation system for remote monitoring and control. The lcd display screen keypad captures pump fault events such as overheat, low voltage, dry-run and motor overload, showing alarm messages on LCD for troubleshooting.

Pentair LCD display screen keypad adopts rotatable front panel design, sealed membrane keypad with splash-proof protection. The pump control interface unit works with 230VAC pump power supply, matched with IntelliProXF 023055 series 3.0HP /3.95 SFHP variable speed pool pump. The pump control interface unit supports 50/60Hz dual frequency operation. The pump control interface unit has built-in watchdog circuit to monitor keypad and display hardware health. The pump control interface unit undergoes strict environmental testing to withstand outdoor sunlight, humidity and temperature fluctuation for pool deck installation. It is a replaceable spare assembly for repairing damaged display or keypad without replacing the whole pump.

This Pentair LCD display screen keypad is widely used on commercial and residential swimming pool circulation systems, paired with Pentair IntelliProXF variable speed pumps for energy-saving pool water circulation and filtration control. The industrial spare part can replace faulty display/keypad assemblies to restore pump local parameter programming, real-time data reading and fault alarm indication rapidly. The industrial spare part matches original mechanical mounting cutout and wiring connectors for direct replacement. The industrial spare part has clear part marking for fast identification and stock management. The industrial spare part reduces pool pump downtime during maintenance and overhaul.
