Model: D664-4383KProduct Type: Electro-hydraulic servo valveBrand: MOOGSeries: D660 seriesUsage: Used for hydraulic speed, pressure and position closed-loop control, suitable for industrial high-precision motion control equipment

Maximum working pressure: 350barRecommended working pressure range: 210bar-315barControl port pressure difference: standard 5barApplicable hydraulic oil: standard mineral hydraulic oilApplicable oil temperature range: -20℃ to +80℃Suitable oil viscosity: 10~400mm²/sOil cleanliness requirement: ISO 18/15 or higher cleanliness levelResponse time: fast dynamic response, stable flow output

Working power supply: 24VDCAllowable voltage fluctuation: 18VDC~32VDCControl input signal: ±10V voltage signalBuilt-in position feedback signal: 4-20mA current signalInternal drive circuit with over-current and short circuit protectionMeet EMC electromagnetic compatibility standard

Working ambient temperature: -30℃ ~ +85℃Storage temperature: -40℃ ~ +95℃Working humidity: 5%~95%RH, no condensationShock and vibration resistance: meet industrial standard vibration resistance requirements

Standard flange installation conforming to international installation dimensionsIntegrated electronic drive structure, compact overall structureInternal jet pipe pilot control structure, high control precisionLow internal leakage, long service life
