1. Dual Protocol: IEC 60870-5-104 Server + PROFIBUS DP Slave

2. Time‑Stamped Data: Supports 104 time synchronization and timestamped events

3. Redundancy: Dual 104 client connections (STARTDT/STOPDT switching)

4. PROFIBUS DP Slave: Up to 122 words I/O, freeze/sync modes, auto‑baud

5. Large Database: 4000 internal registers for data mapping

6. Configuration: Terminal menu + web server + ProSoft Configuration Builder

7. Isolation: Electrical isolation between Ethernet and PROFIBUS ports

8. Diagnostics: Real‑time status, error logs, bus statistics

9. Redundancy: Dual 24 VDC power inputs

10. Temperature: –20°C to +60°C for harsh environments

3. Technical Specifications

3.1 Power Supply

• Rated: 24 VDC

• Range: 18–36 VDC

• Max power: ≤15 W

• Redundancy: Dual terminal blocks

3.2 IEC 60870-5-104 (Ethernet)

• Speed: 10/100 Mbps auto‑negotiation

• Connector: RJ45

• Role: Server (listens for 104 clients)

• Redundancy: Two simultaneous client connections

• Data: ASDU, events, commands, time synchronization

3.3 PROFIBUS DP Slave

• Role: DP Slave (IEC 61158)

• Connector: DB9 female

• Baud rate: 9.6k–12 Mbps, auto‑baud

• I/O data: 122 words input / 122 words output

• Features: Freeze, Sync, auto‑address, GSD file provided

3.4 Internal Database

• Size: 4000 registers (16‑bit words)

• Mapping: 104 ↔ PROFIBUS register‑to‑register

• Data types: Bits, bytes, words, long words, floats

3.5 Environmental

• Operating: –20°C to +60°C

• Storage: –40°C to +85°C

• Humidity: 5%–95% RH, non‑condensing

• Vibration: IEC 60068‑2‑6 compliant

3.6 Physical

• Mounting: 35 mm DIN rail

• Dimensions: 132 × 52.6 × 115 mm

• Weight: ~860 g

• Certifications: CE, UL

4. LED Indicators

• PWR: On = Power normal

• RUN: Blinking = Operating normally

• ENET: Blinking = 104 Ethernet activity

• PBUS: Blinking = PROFIBUS activity

• ERR: On = Fault (config/comm error)

5. Installation & Wiring

1. Mount on DIN rail in cabinet.

2. Connect 24 VDC to power terminals (redundant recommended).

3. Connect Ethernet cable to RJ45 for IEC 60870-5-104.

4. Connect PROFIBUS cable to DB9; use standard PROFIBUS pinout.

5. Set PROFIBUS slave address and baud rate via terminal/web UI.

6. Configure 104 IP, subnet, and data mapping.

7. Save config, reboot, verify communication.

6. Communication Functions

1. 104 → PROFIBUS: Write 104 commands/data to PROFIBUS slave outputs.

2. PROFIBUS → 104: Read slave inputs, timestamp, and send as 104 events.

3. Time Sync: 104 time sync to PROFIBUS (timestamped data).

4. Redundant 104: Dual client connections with automatic failover.

5. Data Integrity: Cyclic I/O with watchdog and error handling.

7. Applications

1. Power & Utility: Connect SCADA (104) to factory PROFIBUS DP I/O/drives.

2. Substation Automation: Integrate protection relays and PROFIBUS devices.

3. Legacy Integration: Bridge older PROFIBUS systems to modern 104 SCADA.

4. Process Control: Water treatment, power plants, and industrial automation.

5. Smart Grid: Enable 104‑based monitoring/control of PROFIBUS equipment.

8. Safety Notes

1. Power Off: Wire only when power is disconnected.

2. Cables: Use shielded cables for both Ethernet and PROFIBUS.

3. Grounding: Properly ground gateway and devices to avoid ESD.

4. Bus Parameters: Match baud rate and slave address on PROFIBUS bus.

5. Environment: Avoid direct sunlight, moisture, and strong EMI sources.
