3G2S6-CPU15 Product Description
Omron 3G2S6-CPU15, also named SYSMAC S6 compact PLC CPU unit, is an integrated programmable logic controller for small machine automation system. It is designed to execute ladder logic program and process local I/O signals, supporting sequential control for old automation equipment renovation.

This CPU delivers reliable logic execution for machine control tasks. The logic execution supports ladder diagram programming with 512 words memory capacity. The logic execution realizes timing, counting and interlock logic processing. Stable logic execution completes standalone automatic operation for small machinery.

The built-in I/O circuit achieves steady signal handling. The signal handling integrates 12 points DC input and 8 points relay output. The signal handling supports expandable I/O points for extended control demands. Accurate signal handling ensures input and output actions follow user control program.

DIN rail mounting structure brings convenient cabinet fitting. Cabinet fitting can be clipped directly inside electrical cabinet. Cabinet fitting connects sensors and actuators via screw terminal block. Flexible cabinet fitting is widely used for legacy SYSMAC S6 system spare replacement.

3G2S6-CPU15 supports memory unit installation and programming console connection function, equipped with dedicated programming port and I/O terminal block. It has LED status indicators for running state and fault diagnosis. Widely applied in conveyor machines, packaging equipment and small process production lines. This product is discontinued by Omron, mainly supplied as industrial spare parts, complying with SYSMAC S6 PLC industrial control standards.
