TRICONEX 2700

Digital Input Module (TMR, SIL3)

Official English Specification Manual (consistent format with 2651/2652/2658)

1. General Description

2. Model Information

• Model: 2700

• Type: Digital Input Module (TMR)

• System Series: Triconex Tricon / Trident SIS

• Safety Level: SIL3 (IEC 61508)

• Certification: TÜV, FM, CSA

• Status: Active / In production

3. Main Features

• Triple Modular Redundancy (TMR): 3 independent input circuits, 2oo3 hardware voting

• 24VDC Discrete Inputs: 32 channels (sink/source selectable)

• Full Channel Diagnostics: Open circuit, short circuit, voltage anomaly detection

• Hot-Swappable: Online replacement without system shutdown

• High Noise Immunity: Galvanic isolation, EMI/RFI filtering

• Fail-Safe Design: Configurable de-energized safe state

• SOE Timestamps: 1ms resolution for sequence-of-events logging

4. Technical Parameters

4.1 Input Specifications

• Signal Type: 24VDC discrete (sink/source)

• Number of Channels: 32

• Input Voltage Range: 18–30VDC

• Logic High: ≥18VDC; Logic Low: ≤5VDC

• Input Current: ~10mA per channel (24VDC)

• Isolation: 1500Vrms channel-to-backplane

• Response Time: ≤8ms

4.2 Redundancy & Safety

• Architecture: TMR (3-channel independent)

• Voting: 2oo3 fault-tolerant

• Diagnostic Coverage: >99%

• System Availability: 99.999%

4.3 Environmental

• Operating Temperature: 0°C to +60°C

• Storage Temperature: −40°C to +85°C

• Relative Humidity: 5%–95% non-condensing

• Vibration: 5–200Hz, 1g

4.4 Power & Physical

• Backplane Power: 5VDC

• Power Consumption: ≤10W

• Dimensions: Standard Trident full-size module

• Weight: ~1.8kg

5. Function Overview

• Acquires 32-channel 24VDC discrete signals from field switches, relays, and sensors

• Three TMR channels sample signals independently; 2oo3 voting ensures data validity

• Diagnostics continuously monitor for faults and report to TriStation

• Supports SOE for time-stamped event analysis

• Integrates with Trident main processors (e.g., 2101) for safety logic execution

6. LED Indicators

• PWR (Green): 5VDC backplane power OK

• RUN (Green): Module active, TMR synchronization normal

• FAULT (Red): Channel/module fault or voting mismatch

• CH (Yellow): Per-channel input status (ON/OFF)

7. Installation & Configuration

1. Insert 2700 into an empty Trident baseplate slot

2. Connect 24VDC field discrete signals to the terminal base

3. Use TriStation 1131 to set sink/source, fault thresholds, and SOE enable

4. Verify: PWR+RUN green; no FAULT red; CH LEDs reflect field status

8. Typical Applications

• ESD emergency shutdown system discrete signal monitoring

• BMS burner management system flame switch/valve position input

• Safety interlock limit switches, pressure switches, and level switches

• Fire & gas system detector status inputs

• Power plant turbine/generator safety sensor monitoring

9. Maintenance

• Hot-swap faulty 2700 without system downtime

• Inspect field 24VDC wiring and terminal connections

• Review fault logs and SOE records via TriStation

• Compatible with Trident TMR main processor 2101

10. Compatibility

• Compatible Systems: Triconex Tricon, Trident SIS

• Configuration Software: TriStation 1131

• Matching Terminal Base: 32-channel 24VDC discrete input base

• Model: 2700

• Description: 32‑Channel 24VDC Digital Input Module, TMR, SIL3
