B&R 8LSA75.DA030S000‑3 Synchronous Servo Motor Product Description

Product Overview

B&R 8LSA75.DA030S000‑3 is a high‑density synchronous servo motor from the B&R 8LSA motor series for high‑performance industrial motion control applications. This B&R synchronous servo motor delivers outstanding dynamic torque output for automated machinery requiring precise positioning and fast acceleration. The B&R 8LSA75.DA030S000‑3 synchronous servo motor adopts self‑cooling construction type A, working with 400 VAC drive systems and supporting single‑cable hybrid connection solutionB& R Indus.... As a robust B&R synchronous servo motor unit, 8LSA75.DA030S000‑3 is fitted with inductive DA 2.2 single‑turn encoder, smooth shaft and swivel‑type SCS connector for flexible on‑site wiring layoutB& R Indus.... B&R 8LSA75.DA030S000‑3 is widely selected for new machine development, mechanical upgrade and spare‑part replacement within B&R ACOPOS drive platforms.

Core Technical Characteristics

B&R 8LSA75.DA030S000‑3 synchronous servo motor provides 30 Nm nominal torque, 43 Nm stall torque and maximum torque up to 187 Nm for heavy‑duty cyclic operationB& R Indus.... This B&R synchronous servo motor runs at 3000 rpm nominal speed with maximum allowable speed reaching 4500 rpm, and its nominal power reaches 9425 W under rated working conditionB& R Indus.... B&R 8LSA75.DA030S000‑3 synchronous servo motor features 5 pole‑pair design, nominal current 18.4 A and stall current 26.38 A to match ACOPOS and ACOPOS P3 servo drive seriesB& R Indus.... The B&R 8LSA75.DA030S000‑3 synchronous servo motor uses flange‑mount installation, centering diameter 180 mm and square flange dimension of 190 mm for stable mechanical assembly onto machine framesB& R Indus.... This B&R synchronous servo motor integrates high‑resolution inductive single‑turn encoder, offering reliable position feedback free from optical component aging risks in dusty industrial environments.

Main Functional Features

B&R 8LSA75.DA030S000‑3 synchronous servo motor achieves accurate speed, torque and position control when paired with B&R servo drives. This B&R synchronous servo motor supports sharp acceleration‑deceleration cycles, minimizing positioning cycle time for high‑speed automated workflows. B&R 8LSA75.DA030S000‑3 synchronous servo motor adopts single‑cable design, combining power and encoder signal inside one hybrid cable to reduce cabinet wiring workload and improve EMC performance. The B&R 8LSA75.DA030S000‑3 synchronous servo motor delivers low cogging torque, ensuring smooth movement even under low‑speed operating conditions. This B&R synchronous servo motor transfers real‑time rotor position data back to the servo drive, enabling closed‑loop motion execution for multi‑axis synchronous motion tasks. B&R 8LSA75.DA030S000‑3 does not come with built‑in holding brake, so external brake modules shall be configured if vertical‑axis anti‑drop function is required.

Typical Application Scenarios

B&R 8LSA75.DA030S000‑3 synchronous servo motor is widely deployed in packaging machines, material‑handling equipment, metal‑processing machinery and robotic automation systems. This B&R synchronous servo motor serves for OEM machine building, production‑line retrofit and replacement of aging 8LSA series servo motor hardware. B&R 8LSA75.DA030S000‑3 synchronous servo motor fits multi‑axis motion‑control setups built on B&R ACOPOS drive systems, where high torque density and dynamic response are essential. In heavy‑load automated production equipment, the B&R synchronous servo motor maintains repeatable positioning accuracy and helps shorten machine tact time for mass‑production workflows.

Installation & Maintenance Notes

Always follow official B&R hardware manuals during installation of B&R 8LSA75.DA030S000‑3 synchronous servo motor. Guarantee correct flange fastening torque and proper shaft coupling alignment for this B&R synchronous servo motor to prevent extra bearing wear. Use matching B&R single hybrid motor cable for B&R 8LSA75.DA030S000‑3 synchronous servo motor and secure swivel connectors tightly for good shielding contact. Inspect connector condition and shaft‑coupling tightness periodically for the B&R synchronous servo motor under high‑vibration operating conditions. Confirm exact part number 8LSA75.DA030S000‑3 before spare‑part swap‑out to guarantee encoder type, shaft style and drive compatibility with existing motion‑control system. Keep adequate air circulation around the synchronous servo motor for effective self‑cooling performance.
