B&R ACOPOSmulti 8B0P0220HC00.001-1（commonly written as 880P0220HC00.001-1）380-500VAC 22A

The 8B0P0220HC00.001-1 is a passive power supply module for B&R ACOPOSmulti multi-axis servo drive system, rated 22A, three-phase input 380–500V AC. This 8B0P0220HC00.001-1 converts AC input into DC bus voltage for supplying multiple ACOPOSmulti inverter modules. It adopts passive rectifier design, no active regenerative function; external braking resistor is required for regenerative energy dissipation. The suffix HC defines cold plate or pass-through cooling mounting variant, 00.001-1 is the hardware revision and factory option code.

This module integrates passive motor short-circuit brake circuit, built-in overvoltage, overcurrent and over-temperature protection. It communicates with the ACOPOSmulti backplane, status LEDs display power, run and fault diagnosis. It works with ACOPOSmulti inverter modules, auxiliary supply and capacitor modules on the shared mounting plate. Configuration and commissioning are completed via Automation Studio software. It supports DNA dynamic node allocation, with CE, UL, cULus certifications. Hot-swap is not allowed; rack power-off is required for replacement.

The 8B0P0220HC00.001-1 is widely used in packaging machinery, printing lines, textile equipment and automated handling high-precision multi-axis motion control. This ACOPOSmulti series module is still supported by B&R. Many automation maintenance teams stock this unit as spare power supply for servo rack overhaul and emergency replacement. Cooling type and revision code must be strictly matched before spare swap.
