Allen‑Bradley 2711‑K10C1L1

The 2711‑K10C1L1 is a PanelView 1000 Standard keypad‑type color HMI terminal from Rockwell Automation Allen‑Bradley, powered by 24VDC, rated 1A at 24VDC (max 24W). This 2711‑K10C1L1 features 10.4‑inch color TFT screen, 640×480 resolution, built‑in stainless steel membrane keypad with 16 function keys. The suffix L1 indicates DC power variant, no AC power support.

This 2711‑K10C1L1 includes RS232 serial port for PLC communication, supporting DF1 protocol to connect with SLC500, MicroLogix and Logix controllers. It is programmed with PanelBuilder32 software. Front panel IP65, NEMA 12/13/4X indoor rating, reverse polarity and overvoltage protection integrated. It supports alarm display, recipe management, data logging and real‑time trend for factory floor operation.

The 2711‑K10C1L1 is widely used on packaging, material handling, water treatment and general automation production lines. This classic PanelView Standard series is discontinued by Rockwell. Most available 2711‑K10C1L1 units are tested surplus spare parts for cabinet overhaul and emergency HMI replacement.
