Core Measurement Principle & Electrical Performance

This portable host processes ultrasonic signals transmitted and received by external clamp-on transducers. Built-in high-speed digital signal processing unit filters clutter interference caused by pipeline scaling, fluid impurities and field electromagnetic environment, improving the stability of echo signals. It can calculate flow velocity, volumetric flow rate, mass flow rate and cumulative flow volume in real time, and supports multiple standard data output modes including local display, data storage and wired communication. The whole machine is calibrated strictly before delivery, with high repeatability and measurement precision within the applicable pipe diameter and medium range. Equipped with internal power management module, it supports long-time battery-powered outdoor field measurement tasks, and the built-in storage space can record historical measurement data for later data analysis and archiving. Internal circuits are designed with surge protection to avoid instantaneous voltage impact damage during field wiring operation.

Structural Design & Environmental Adaptability

The whole machine uses a wear-resistant reinforced handheld casing with dustproof, waterproof and anti-drop characteristics, adapting to complex working conditions such as construction sites, outdoor pipe galleries and workshop equipment maintenance areas. The internal circuit board is covered with anti-corrosion protective coating to resist humid air, dust and weak corrosive gas in petrochemical, water supply, thermal power and metallurgical sites. The equipment complies with industrial EMC standards and can normally collect measuring signals near on-site motors, frequency converters and high-power electrical equipment. The human-machine interface is equipped with a clear display screen and physical operation keys, convenient for field staff to set pipe parameters, medium parameters and view real-time measuring values. The compact portable structure is easy to carry and deploy without fixed installation construction.

Matching Components & Application Scenarios

It supports matching with multiple types of Panametrics clamp-on ultrasonic probes, forming a complete non-cutting pipeline flow measurement system. Widely used in pipeline flow regular inspection, water supply and drainage pipeline flow verification, circulating water system balance testing, petrochemical medium flow spot check, fire pipeline detection and energy consumption statistical testing in various industries. It is commonly used for temporary flow monitoring, pipeline blockage diagnosis and instrument calibration comparison. When the original portable meter fails in signal processing or data display, this model can serve as replacement equipment to guarantee the progress of field measurement work.

Operational Stability & Maintenance Features

Complete aging test, precision calibration and whole machine function detection are carried out before factory delivery to control the failure rate of long-term field use. Measurement parameters and historical stored data have power-off retention function to prevent data loss after accidental shutdown. Daily maintenance only needs regular inspection of host interfaces, battery health and cable integrity, with low maintenance threshold and operation cost. Original GE portable flow meters effectively reduce measurement errors brought by low-cost imitation equipment, improving the authenticity of field test data. The original packaging can realize long-term inventory storage, and the overall performance will not deteriorate obviously under dry storage environment.
