Model Interpretation

AS: Modicon Automation System

B826: 32‑point DC output module (true‑high)

032: 24VDC, 32 points, 1 common group, standard diagnostics

Technical Parameters

Outputs: 32 channels, 24VDC nominal

Logic: True‑high (source, +24VDC = ON)

Operating Voltage: 20–28VDC (continuous)

Current Rating: 250mA max per point; 8A max per module (1 group)

Leakage Current: ≤0.1mA (OFF state)

Isolation: Optical coupling, 1500VAC channel‑to‑backplane

Response Time: ≤1ms (ON/OFF)

Backplane Power: +5V 90mA; +4.3V 1mA

External Power: 24VDC ±4%, 600mA (excluding load)

Operating Temp: 0°C to +55°C

Storage Temp: -40°C to +85°C

Humidity: 5%–95% non‑condensing

Weight: ≈1.0kg

Dimensions: 50×119×125mm

Origin: France

Interface & Configuration

Backplane: Modicon 800/984 I/O bus

Terminals: Screw terminals (32 outputs, 1 common)

Indicators: LED per channel (ON when active)

Fuses: No field‑replaceable fuses (single group design)

Wiring: 0.5–2.5mm² copper wires

Terminal Connector: AS‑8534‑000

Core Functions

High‑Density DC Load Driving: 32‑point true‑high output for 24VDC relays, solenoids, contactors

Single‑Group Simplified Wiring: 32 points share one common for reduced wiring complexity

Optical Isolation: Reduces electrical noise and ground loops

Status Visibility: Individual LEDs for quick channel state checks

Surge Protection: Basic voltage spike immunity for industrial environments

Applications

Systems: Modicon 800, 984, 300‑series PLCs

Industries: Material handling, packaging, automotive, general automation

Use Cases: Relay coils, motor starters, solenoid valves, indicator lamps

Compatibility

Racks: Modicon 800/984 8/11‑slot backplanes

CPUs: AS‑984B‑128, PC‑E984‑685, AS‑9370‑001

Software: Concept, ProWORX 32, P190
