CI534V02 / 3BSE010700R1 English Technical Parameters & Usage Instructions & Precautions
Basic Information
Manufacturer: ABB
Product Type: MODBUS Communication Submodule (AC 800M Series)
Part Number Combination: CI534V02 (Module Assembly), 3BSE010700R1 (Official Factory Part Number)
Application: ABB AC800M Controller Rack, MODBUS RTU serial communication, third-party device connection, industrial instrument data acquisition, serial protocol conversion
Description
CI534V02 / 3BSE010700R1 English Technical Parameters & Usage Instructions & Precautions
Basic Information
Manufacturer: ABB
Product Type: MODBUS Communication Submodule (AC 800M Series)
Part Number Combination: CI534V02 (Module Assembly), 3BSE010700R1 (Official Factory Part Number)
Application: ABB AC800M Controller Rack, MODBUS RTU serial communication, third-party device connection, industrial instrument data acquisition, serial protocol conversion
1. CI534V02 Technical Parameters
Communication Protocol: MODBUS RTU Industrial Serial Protocol
Channel Configuration: 2 Independent Isolated Serial Channels
Interface Standard: RS232 / RS485 Programmable Interface
Baud Rate Range: 300 ~ 115200 bps Adjustable
Power Supply: Powered by Rack Backplane (No External Power Required)
Current Consumption: 0.18 A @5VDC
Total Power Dissipation: ≤ 0.90 W
Transmission Distance: Max 1200 Meters (RS485 Mode)
Isolation Voltage: 2000 Vrms Galvanic Isolation
Working Temperature: -20℃ ~ +60℃
Storage Temperature: -40℃ ~ +85℃
Ambient Humidity: 5%~95% RH (Non-condensing)
Protection Grade: IP20
2. Internal Circuit & Function Description
Core Function: MODBUS RTU data transceiver, serial signal conversion, third-party device communication and protocol parsing
Signal Processing: Serial signal encoding, decoding, waveform shaping and noise filtering
Dual-channel Design: Two independent serial ports support simultaneous master-slave communication
Anti-interference: Industrial EMI&EMC anti-surge and differential signal anti-interference circuit
Protection Mode: Overvoltage, overcurrent, static and reverse polarity protection
Structure: Small submodule card, high-density PCB, conformal coating anti-corrosion treatment
3. Usage Instructions
Installation: Insert into SC510 / SC520 / SC520M carrier board slot; horizontal installation inside control cabinet.
Wiring: Use shielded twisted-pair cables for serial lines; adopt bus topology for RS485 connection.
Debugging: Set baud rate, parity bit and station address via Control Builder software.
Operation: Observe communication status LED; monitor serial data transmission stability in real time.
Maintenance: Regularly clean dust; check terminal fastening and shielding layer grounding condition every six months.
4. Important Precautions
Do not install in humid, condensed water, dusty and corrosive gas environments.
Keep away from high-power frequency converters to avoid serial signal distortion.
Cut off all power supply before insertion, removal and wiring operations.
Prohibit excessive voltage input on serial port to prevent internal communication chip burnout.
Avoid severe vibration and mechanical impact during transportation and installation.
Ensure cabinet ventilation to prevent communication delay caused by high temperature.
Unauthorized disassembly of internal components is strictly prohibited.
5. General Technical Characteristics
Certification: CE, UL, RoHS
Installation Method: Submodule Plug-in Mount
