PP875 3BSE092977R1
Basic Information
Manufacturer: ABB
Product Type: Industrial TFT Touch Screen Panel (Panel 800 Series)
Part Number Combination: PP875 (HMI Assembly), 3BSE092977R1 (Official Part Number)
Application: ABB 800xA DCS system, industrial automation control, power plant monitoring, process industry human-machine interaction
Description
Basic Information
Manufacturer: ABB
Product Type: Industrial TFT Touch Screen Panel (Panel 800 Series)
Part Number Combination: PP875 (HMI Assembly), 3BSE092977R1 (Official Part Number)
Application: ABB 800xA DCS system, industrial automation control, power plant monitoring, process industry human-machine interaction
1. PP875 HMI Operator Panel
Display Type: 7.0 inch TFT-LCD Widescreen Color Screen (16:9)
Resolution: 800 × 480 Pixels, True Color
Backlight Type: LED Backlight, Service Life ≥80000 Hours (25℃)
Touch Screen: Resistive Touch Panel, Industrial Grade
CPU Processor: 1.0GHz Industrial Embedded Processor
Memory: 512MB RAM, 4GB Built-in Flash Memory
Operating System: Windows Embedded CE 7.0
Communication Interface: Dual Ethernet, RS232, RS485, USB 2.0 Port
Communication Protocol: Modbus TCP, Modbus RTU, Profibus, OPC UA
Working Voltage: 24 VDC (18~32 VDC)
Rated Current: 0.50 A (Normal), Max 1.00 A
Operating Temperature: -20℃ ~ +60℃ (Vertical Installation)
Protection Grade: Front IP65, Rear IP20
2. 3BSE092977R1 Control Board
Function: Built-in main control circuit, high-speed signal processing, data storage and multi-protocol communication management
Anti-interference: Industrial EMI & EMC anti-interference suppression design
Insulation Strength: 2500 Vrms Isolation Protection
Structure: High-density integrated circuit layout, anti-shock and dustproof reinforcement
3. Usage Instructions
Installation: Adopt panel embedded installation; keep vertical installation, avoid tilted and upside-down mounting.
Wiring: Use shielded cables for signal lines; separate strong current and weak current wiring to avoid electromagnetic interference.
Debugging: Complete program download and configuration via ABB Panel Builder 800 V6.2 or higher version.
Operation: Operate with finger or soft industrial stylus; prohibit sharp hard objects touching the screen.
Maintenance: Clean the panel surface with dry soft cloth regularly; do not use corrosive liquid or chemical detergent.
4. Important Precautions
Do not install in environments with heavy dust, moisture, corrosive gas or strong electromagnetic interference.
Maintain stable 24VDC power supply; overvoltage and surge current are strictly forbidden.
Cut off the power supply before wiring, disassembly and daily maintenance.
Avoid severe mechanical collision and strong vibration during transportation and installation.
Keep rear ventilation smooth to prevent overheating and component aging.
Non-professional personnel are not allowed to disassemble the internal circuit board.
General Technical Characteristics
Certification: CE, UL, RoHS
Installation Method: Panel Mount
