216EA62 1MRB150083R1 F 1MRB178066R1 F
Basic Information
Manufacturer: ABB
Product Type: Industrial Excitation Control Module, Advant Series
Part Number Combination: 216EA62 (Main Board), 1MRB150083R1 F (Auxiliary Board), 1MRB178066R1 F (Backplane Board)
Application: Power plant excitation system, industrial process control, signal acquisition and processing
Description
Basic Information
Manufacturer: ABB
Product Type: Industrial Excitation Control Module, Advant Series
Part Number Combination: 216EA62 (Main Board), 1MRB150083R1 F (Auxiliary Board), 1MRB178066R1 F (Backplane Board)
Application: Power plant excitation system, industrial process control, signal acquisition and processing
1. 216EA62 Main Control Board
Signal Type: Analog Voltage / Current Signal
Input Range: 0-10 VDC, 4-20 mA
Resolution: 16-bit A/D Conversion
Precision: ±0.1% Full Scale
Sampling Frequency: 600 Hz
Communication Interface: CANopen, Modbus RTU
Working Voltage: 24 VDC ±10%
Power Consumption: ≤15 W
Operating Temperature: -20℃ ~ +70℃
Protection Grade: IP20
2. 1MRB150083R1 F Auxiliary Interface Board
Function: Signal Conditioning, Electrical Isolation, Digital I/O Expansion
Isolation Voltage: 2500 Vrms
Digital Input: 16 Channels (24 VDC Logic)
Digital Output: 8 Relay Output Channels
Contact Capacity: 2 A (250 VAC / 30 VDC)
Working Voltage: 24 VDC
Operating Temperature: -25℃ ~ +70℃
3. 1MRB178066R1 F Backplane Power Board
Input Voltage: 85~264 VAC, 50/60 Hz
Output Voltage: 24 VDC
Max Output Current: 5 A
Ripple Noise: ≤50 mVp-p
Protection Function: Overcurrent, Overvoltage, Short Circuit, Thermal Protection
General Technical Characteristics
Certification: CE, UL, CSA, RoHS
Installation Method: Chassis Mount
Anti-interference: Built-in EMI Filter
Get a Quote
