cFP-2100

National Instruments Compact FieldPoint Real-Time Controller

1. General Description

2. Part Number

3. Key Specifications

• Processor: 188 MHz real-time CPU

• Memory: 64 MB DRAM, 64 MB onboard non-volatile storage

• Storage expansion: CompactFlash slot

• I/O Slots: 8 slots for hot-swappable cFP I/O modules

• Communication Interfaces:

  • 10/100 Mbps Ethernet RJ45

  • 1 × RS-232 DB9 serial port

• Supported protocols: Modbus TCP, Modbus RTU, OPC, NI FieldPoint protocol

• Operating System: Pre-installed LabVIEW Real-Time

• Programming: LabVIEW Real-Time, NI MAX configuration software

• Power Input: 11 VDC to 30 VDC, 24 VDC nominal, redundant power support

• Operating Temperature: -20 °C to +55 °C

• Mounting: DIN rail or panel mount

• Status: Discontinued / EOL

4. Main Features

• Higher performance than cFP-20xx series with faster CPU and larger memory

• All-in-one design: integrated real-time controller and 8-slot backplane

• Standalone operation, able to run control programs without a host PC

• Supports hot swapping of cFP I/O modules for online maintenance

• Industrial rugged design with isolation and transient overvoltage protection

• Compact size suitable for factory floor and remote field installation

5. Compatible Modules

• Analog input and analog output modules

• Digital input / output modules

• Thermocouple, RTD, relay, and counter/timer modules

6. Applications

• Industrial distributed real-time control systems

• Factory automation and process monitoring

• Remote field data acquisition and standalone data logging

• Building automation and environmental monitoring

• Upgrade and maintenance of legacy Compact FieldPoint systems
