Eaton 1250A Air Circuit Breaker

The Eaton 1250A is a heavy-duty low voltage air circuit breaker from the Eaton IZMX / IZM9 series, rated at 1250A for main incoming and large feeder protection in industrial distribution switchgear. This Eaton 1250A is designed for selective coordination within multi-level LV power systems, delivering overload, short-circuit and earth fault protection for transformer secondary circuits and heavy-load feeders. The Eaton 1250A is widely supplied as an original spare and retrofit component for factory, power plant and commercial electrical cabinets.

The Eaton 1250A complies with IEC 60947-2 standard and belongs to utilization category B. It adopts withdrawable draw-out construction, which simplifies testing, inspection and replacement without removing the main busbar connections. The electronic trip unit of the Eaton 1250A supports adjustable long-time, short-time delay and instantaneous protection curves. Optional accessories including auxiliary contacts, alarm contacts, shunt release and undervoltage release can be fitted to the Eaton 1250A, providing breaker status and fault alarm signals for PLC and SCADA interlock systems. Manual and motor-operated mechanisms are available for local and remote operation.

This Eaton 1250A is engineered for cabinet mounting inside LV switchboards. The Eaton 1250A has robust mechanical endurance and EMC performance, suitable for factory environments with vibration and electromagnetic interference. It supports high short-circuit breaking capacity to limit fault propagation and reduce blackout scope. Built-in event recording and waveform capture functions of the Eaton 1250A help maintenance engineers carry out post-trip fault analysis. The trip parameters can be retained after direct replacement to cut commissioning time.

The Eaton 1250A is commonly deployed in mining power distribution centers, water treatment facilities, manufacturing plants and building main power systems. Replacing a faulty protection unit with the Eaton 1250A quickly restores circuit protection and isolation capacity. As a mature heavy-current ACB from Eaton, the Eaton 1250A provides reliable fault isolation for users maintaining legacy low voltage distribution infrastructure. Static protection must be followed while handling the Eaton 1250A to protect the electronic trip unit.
