WOODWARD 9905-966 LINKNET 6 CHANNEL TC INPUT MODULE 24VDC REV M

WOODWARD 9905-966 REV M is a LINKNET thermocouple input module for Woodward 723PLUS / DSLC digital engine and generator control systems, powered by 24VDC supply. The tc input module provides six independent thermocouple input channels to continuously measure temperature signals from engine exhaust, lube oil and other process temperature sensors. The tc input module converts low-level millivolt thermocouple signals into digital data and transmits readings to the main Woodward controller via LINKnet fieldbus communication. The tc input module supports common thermocouple types such as J, K and T, with built-in cold junction compensation to guarantee accurate temperature measurement. The tc input module has channel over-range detection and open-sensor wire fault alarm for sensor circuit health monitoring.

WOODWARD 9905-966 LINKNET TC module adopts rack-mounted design for installation inside marine and industrial engine control cabinets. The temperature acquisition board features LED status indicators for module power, LINKnet bus communication and individual channel fault alerts. The temperature acquisition board supports configurable channel scaling and filter parameters to reduce noise interference from engine power networks. The temperature acquisition board holds galvanic isolation between field sensor wiring and internal control circuits to avoid ground loop disturbance. The temperature acquisition board is fully compatible with Woodward DSLC, 723PLUS and MSLC power management controllers for genset and marine engine monitoring. The temperature acquisition board undergoes factory functional testing to maintain stable operation under vibration and temperature variation.

WOODWARD 9905-966 is widely used onboard marine vessels, power plants and industrial engine stations for diesel generator exhaust temperature and machinery thermal monitoring systems. The industrial spare part can replace defective thermocouple input modules to restore multi-channel temperature signal collection and LINKnet data transmission rapidly. The industrial spare part matches original electrical and mechanical specifications for direct rack plug-in replacement. The industrial spare part has clear part marking for fast identification and stock management. The industrial spare part reduces engine control system downtime during overhaul and preventive maintenance.
