Schneider BSH1004P11A2A Servo Motor
Schneider BSH1004P11A2A is a Lexium 05 series low inertia AC servo motor, compatible with Lexium 05, Lexium15 and Lexium32 servo drives for high-precision motion control applications. This AC servo motor adopts 100mm IEC standard flange, keyed shaft design, single-turn Sincos encoder feedback, delivering stable torque output for positioning, speed and synchronization control. The AC servo motor uses natural convection cooling, IP50 protection rating, no built-in holding brake, suitable for packaging, machine tool, material handling and automated production line axes. The AC servo motor serves as core motion spare part for automation machine overhaul and servo axis retrofit.

This BSH1004P11A2A unit, continuous stall torque 9.31 N.m, rated speed 1500 rpm, max mechanical speed 6000 rpm, rotor inertia 4.22 kg.cm², 4 poles, three-phase power supply up to 480VAC. BSH1004P11A2A features angular power and encoder connectors, compact housing, compliant with CE and IEC industrial standards. BSH1004P11A2A is widely used in industrial automation equipment, CNC machinery and robotic auxiliary axis control systems.

As high dynamic motion hardware, this Schneider BSH servo motor provides fast response and accurate positioning for automated machinery. Schneider Lexium BSH series spare parts include BSH servo motors, encoder cables, power cables, sealing kits, bearing assemblies and Lexium servo drives for motion control system maintenance. Schneider Lexium 05 AC servo motors are trusted replacement units for industrial servo motion control systems.
