I. Model Segmentation Explanation

CSB01.1C: CSB01 series control card, version 01.1, C-type expandable architecture

S3: Communication interface SERCOS III, dual RJ45 Ethernet hard real-time bus, 100Mbps, minimum communication cycle 250μs

ENS: Main encoder interface, 12V power supply, compatible with Hiperface/1Vpp sine wave / TTL square wave / IndraDyn dedicated encoder

NNN: No additional expansion modules such as second encoder, analog quantity, encoder simulation, etc.

NN: No integrated STO / startup interlock and other safety functions

S: Standard single-line LED display + 4-button local operation panel

NN: No additional special function modules

FW: Factory pre-installed complete firmware and authorization, plug-and-play

II. Core Parameters

Power supply: DC24V ±10%, typical power consumption 7.5~8W

Number of control axes: Single axis

Control cycle: Current loop 125μs, speed loop 250μs, position loop 500μs

Interfaces: SERCOS III dual network ports, RS232 debugging port, standard digital I/O (5DI/3DI/O/1 relay output)

Protection level: IP20 (installed in the control cabinet)

Dimensions: 350×80×220mm, weight approximately 1.2kg

III. Comparison of the Basic Model S3 in the Same Series Table

Full model Safety configuration Applicable scenarios

CSB01.1C-S3-ENS-NNN-NN-S-NN-FW No safety General basic model, no safety specification requirements

CSB01.1C-S3-ENS-NNN-L1-S-NN-FW L1 start interlock Prevent accidental start, ordinary safety requirements

CSB01.1C-S3-ENS-NNN-L2-S-NN-FW L2 STO SIL3 High safety conditions, machine tools / automotive equipment

Four. Functions and Adaptation

Native support for SERCOS III real-time bus, high multi-axis synchronization accuracy, small jitter, suitable for all force control systems of Schaeffler.

Pure single encoder configuration, simple wiring, only realizes single closed-loop control of the motor.

C-shaped reserved expansion slot, later can be equipped with encoders, analog quantities, safety modules for upgrade functions.

Adapt to HCS01/HCS02/HCS03 power units, equipped with MSK, MHD series servo motors.

Five. Application Scenarios

Standard automation equipment with SERCOS III bus architecture, ordinary CNC machines, multi-axis synchronous production lines, textile / printing machinery; mostly used for spare parts replacement, economic servo system construction, suitable for situations without safety shutdown and without expansion requirements.
