Emerson 1X00797H01L Product Description

Emerson 1X00797H01L is a high power DIN rail mounted 24VDC power supply module of Ovation DCS 1X series, originally designed by Westinghouse. It provides stable and continuous power supply for Ovation controllers, I/O units, communication cards and field industrial instruments. Equipped with wide voltage input, high efficiency power conversion and full protection circuit, this module supports redundant parallel operation and hot swap maintenance. It maintains stable working performance under complex industrial conditions, and serves as the core power distribution unit widely used in power, chemical, oil gas and metallurgy industries.

The module accepts universal AC input ranging from 85VAC to 264VAC with frequency 47Hz to 63Hz, adapting to different power grid standards worldwide. It outputs constant 24VDC power with rated continuous current 20A and rated power 480W. Low ripple and noise design effectively avoid signal interference, and voltage fluctuation stays within small range under variable load conditions to guarantee consistent power supply quality.

Adopting high performance power conversion circuit, the maximum conversion efficiency reaches 90%. Natural convection fanless cooling structure eliminates failure risks caused by fan aging and dust accumulation. Industrial grade circuit coating enhances internal insulation, enabling long time stable operation in dusty, humid and salt mist environments.

Built with complete protection functions including overload protection, short circuit protection, overvoltage protection, overtemperature protection and reverse polarity protection. The module limits current automatically when overload occurs and recovers after fault removal. It cuts off output instantly to prevent component damage once short circuit, overvoltage or overheating happens. Reverse connection lock function effectively avoids burnout caused by wrong wiring.

Supports dual module redundant parallel connection with automatic load sharing. When one power module breaks down, the other module takes over all power supply work within 10ms without power interruption and data loss. Standard DIN rail installation allows online hot swap replacement. Maintenance work can be finished without shutting down the whole DCS system, effectively reducing production downtime.

Operating temperature ranges from 0 degree Celsius to 55 degree Celsius, storage temperature covers minus 40 degree Celsius to 85 degree Celsius. The mechanical structure meets international vibration and shock resistance standards, resisting impact and vibration generated by on-site mechanical equipment. It keeps reliable operation under extreme temperature change and harsh working surroundings.

Front panel LED indicators directly display power supply, running and fault status for quick on-site inspection. Remote monitoring function supports real time viewing of output voltage, operating current, internal temperature and fault records. The module is fully compatible with Ovation DCS system version 3.7 and above, matching OCR series controllers and all 1X series I/O modules, easy for system expansion and spare parts replacement.

Model: 1X00797H01LBrand: EmersonSeries: Ovation DCS 1X SeriesInput Voltage: 85VAC~264VAC, 47Hz~63HzOutput Voltage: 24VDCRated Output Current: 20ARated Power: 480WMaximum Conversion Efficiency: 90%Isolation Strength: Reinforced isolation between input and outputProtection Function: Overload, short circuit, overvoltage, overtemperature, reverse polarityCooling Mode: Natural convection coolingInstallation Type: 35mm standard DIN railOperating Temperature: 0℃ ~ 55℃Storage Temperature: -40℃ ~ 85℃Ambient Humidity: 5%~95% non condensingVibration and Shock Resistance: Compliant with IEC 60068-2-6 and IEC 60068-2-27Certification: CE, UL, RoHSProtection Level: IP20Overall Dimension: 60mm×125mm×35mmWeight: 1.2kg~1.6kgWarranty Period: 12 months original factory warranty

High power output capacity meets power demand of large scale I/O cabinet and multiple field devices. Redundant failover design ensures uninterrupted power supply for critical production process. Fanless maintenance free structure lowers daily operation cost. Rugged design adapts various harsh industrial working conditions. Universal power input and standard protocol compatibility realize convenient installation and flexible system upgrading. Visual status display and remote diagnosis shorten fault troubleshooting time.

Power generation industry, applied in thermal power, hydropower and nuclear power plant DCS control cabinet to supply power for control loop and safety interlock equipment. Oil and gas industry, suitable for offshore platform, long distance pipeline and storage station automation control system. Chemical industry, used in refining, chemical synthesis and fertilizer production process control unit. Metallurgy industry, matched with blast furnace, rolling and continuous casting production line control equipment. Water treatment, pharmaceutical, papermaking and other manufacturing industries, providing stable power support for automatic monitoring and control system.

Install the module on vacant standard DIN rail inside cabinet, reserve enough ventilation space and keep distance from high power interference equipment. Fasten the module firmly and leave proper gap between adjacent modules for heat dissipation. Select matched copper wire for wiring, strictly distinguish positive and negative polarity. Separate power cable and signal cable to reduce electromagnetic interference. Equip overload protection switch on input and output terminal.

Check indicator light and module appearance every week, inspect wiring tightness and surface dust accumulation regularly. Clean dust with dry soft cloth, avoid corrosive cleaning liquid. Observe remote operation data daily to master real time operating condition.

Cut off external load power when fault occurs. Check input power supply, wiring circuit and load working state. Confirm overload and short circuit problems first. Restart the module after troubleshooting. Replace spare module timely if internal hardware failure appears.

Product Model: 1X00797H01LProduct Type: 24VDC High Power DIN Rail Power Supply ModuleApplicable System: Ovation DCS SystemMain Function: Wide voltage power input, stable DC output, multi protection, redundant backup, hot swap maintenancePackage: Original anti static sealed package equipped with operation manual, qualification certificate and installation accessoriesAfter Sales Service: 12 months warranty and professional technical support
