2. Basic Information

Structure: The main control computing unit, signal interface, and bus communication module are integrated together.

Installation method: Standard electrical guide rail installation.

Protection level: IP20

Operating temperature: 0℃~45℃

Environmental humidity: ≤90%, no condensation

Equipment status: Common spare parts for industrial use

3. Electrical Parameters

Working power supply: DC 24V

Supported control axes: 4 axes

Compatible with incremental and absolute encoder signals

Built-in electrical isolation protection, strong anti-interference ability

4. Core Functions

Realize single-axis position control and multi-axis synchronous linkage control

Support electronic gears, cam following, and trimming process mode

Built-in logic operation, can independently complete process control

Real-time monitoring of equipment operation status, automatic fault alarm

5. Performance Parameters

Fast operation response speed, excellent positioning accuracy

Multiple protections against overvoltage, undervoltage, overload, and short circuit

Smooth operation, suitable for high-frequency start-up and stop conditions

Data is stored even when power is off, parameters are not easily lost

6. Ancillary Accessories

Communication shielded cable

Encoder connection cable

Guide rail fixing component

Program debugging software

7. Application Scope

Printing and packaging machinery equipment

Lithium battery and photovoltaic automation production line

Machine tool feed axis control system

Replacement and repair of old equipment with the same specification modules
