1. Product Overview
1.1 Basic Information
Manufacturer: SEW-EURODRIVE
Product Series: MOVITRAC
Full Model: 1122-403-4-00
Product Type: Three-phase input AC frequency inverter
Usage: Speed regulation and soft start control for three-phase asynchronous motors, widely used in industrial automation, fans, water pumps, conveying equipment and mechanical transmission systems.
1.2 Model Code Definition
1122 : Rated power code (2.2kW)
403 : 230V low voltage level specification
4 : Three-phase AC power input
00 : Standard basic configuration without extra accessories
2. Main Electrical Specifications
2.1 Input Power Parameters
Input Voltage: 3-phase AC 200V ~ 240V (Nominal 230V)
Input Frequency: 50Hz / 60Hz
Allowable Voltage Fluctuation: ±10%
2.2 Output Power Parameters
Rated Output Power: 2.2 kW
Rated Output Current: 8.0 A
Output Voltage Range: 0 ~ 230V three-phase AC
Output Frequency Range: 0 ~ 400 Hz
Basic Control Mode: Standard V/F open-loop control
2.3 Load & Overload Capacity
125% rated current: Long-term continuous operation
150% rated current: Short-time overload operation within 60 seconds
3. Physical & Environmental Parameters
Protection Grade: IP20
Heat Dissipation Mode: Natural air cooling
Working Ambient Temperature: 0°C ~ +45°C
Storage Temperature: -25°C ~ +70°C
Working Humidity: 5% ~ 95%, non-condensing
Installation Method: Vertical wall-mounted installation
Installation Clearance: Keep enough space for heat dissipation up and down
4. Control Function & Interfaces
4.1 Control Modes
Local panel manual control
External terminal signal control
Analog signal speed regulation control
RS485 remote communication control
4.2 Built-in Standard Interfaces
RS485 communication port
Multi-group digital input terminals
Multi-group relay signal output terminals
0-10V analog speed regulating input interface
4.3 Practical Functions
Built-in dynamic braking function to realize fast stop
Acceleration and deceleration time freely adjustable
Energy-saving operation mode
Multi-segment fixed speed operation function
5. Complete Protection Functions
Over-current protection
Over-voltage and under-voltage protection
Motor overload electronic thermal protection
Inverter internal over-temperature protection
Output short-circuit protection
Ground fault protection
Anti-stall running protection
6. Installation & Wiring Requirements
6.1 Installation Rules
Install on flat, dry and dust-free rigid surface
Keep away from corrosive gas, oil mist and strong vibration environment
Prohibit sealing and covering the heat dissipation holes
6.2 Wiring Rules
Power line and control line shall be wired separately to avoid signal interference
Motor output cable is recommended to use shielded cable
Must connect reliable protective grounding wire
All wiring operations must be performed after cutting off the total power supply
7. Commissioning & Operation Steps
Complete all wiring and check no short circuit or wrong wiring
Confirm the power supply voltage matches the inverter specification
Power on and enter the factory default state
Set basic parameters: motor rated voltage, rated current, upper and lower limit frequency, acceleration/deceleration time
Select the required control mode
Trial run without load first, confirm no abnormal noise and abnormal vibration
Formal load operation after normal no-load operation
8. Daily Maintenance & Inspection
Regularly clean dust on the surface and heat dissipation holes
Regularly check whether terminal wiring is loose
Check the operating temperature and running sound during operation
Long-term shutdown should be placed in dry and ventilated place
Professional electrical personnel shall perform maintenance and fault handling
9. Common Faults & Simple Troubleshooting
Over-current fault: Check motor stuck, wiring short circuit, shorten acceleration time
Over-voltage fault: Check input power stability, extend deceleration time
Over-temperature fault: Clean dust, improve heat dissipation environment
Overload fault: Reduce mechanical load, match motor power reasonably
10. Application Scope
Industrial assembly line conveyor equipment
Industrial exhaust fan and cooling fan speed control
Small and medium-sized water pump energy-saving speed regulation
Packaging machinery, printing machinery auxiliary transmission mechanism
Other general three-phase motor variable speed drive occasions
11. Compliance Standard
Comply with EU CE safety certification
Meet industrial frequency converter EMC electromagnetic compatibility standard
Meet low-voltage electrical safety use standard
