2. General Description

• Type: Shielded RS232 (DB9) serial extension cable

• Connectors: DB9 male ↔ DB9 female (both ends, molded with thumbscrews)

• Cable Gauge: 28 AWG, multi‑strand copper

• Shielding: 100% foil + braid coverage (EMI/RFI protection)

• Jacket: Industrial beige PVC, robust strain relief

• Standard Length: Typically 15 ft (4.57 m); other lengths available (6′/10′/25′/50′/100′)

3. Key Features

• Woodward OEM Compatible – Direct fit for 505/505E/505XT and MicroNet systems

• Full Shielding – Foil + braid eliminates EMI/RFI interference

• Industrial Grade – Oil/chemical resistant, molded strain relief

• Secure Connection – DB9 with thumbscrews (no loose connections)

• Wide Temperature – −40 °C to +85 °C

• Plug‑and‑Play – No configuration needed for serial links

• CE/UL/RoHS – Global compliance

4. Technical Specifications

• Part Number: 5417-413

• Manufacturer: Woodward (USA)

• Product Type: RS232 Serial Extension Cable (DB9)

• Connector: DB9 Male (PC side) ↔ DB9 Female (Woodward side)

• Conductor: 28 AWG stranded copper

• Shield: Double (foil + braid), 100% coverage

• Jacket: Beige industrial PVC

• Length: 15 ft (4.57 m) standard

• Voltage Rating: 30 V DC max

• Operating Temp: −40 °C to +85 °C

• Weight: Approx. 0.25 kg (0.55 lbs)

• Compatibility: 505/505E/505XT, MicroNet Plus, PC/HMI/serial devices

5. Applications

• 505 Governor Programming – Connecting PC to 505/505E/505XT for configuration

• MicroNet System Debug – Serial link between controller and laptop/HMI

• Turbine Control Monitoring – Real‑time data logging via RS232

• Industrial Automation – EMI‑prone environments (power plants, oil/gas)

6. Ordering Information

• Part Number: 5417-413

• Description: Woodward 5417-413 Shielded RS232 Serial Extension Cable, DB9 Male/Female, 15 ft (4.57 m), Double Shielded, for 505/MicroNet Programming & Communication
