2. General Description

• Type: MicroNet high‑density analog/discrete cable assembly

• Length: 16 ft (4.88 m)

• Connectors: Factory‑molded, keyed MicroNet connectors (both ends)

• Signal Types: Analog (4–20 mA / 0–10 V) + discrete (24 Vdc digital)

• Construction: Double shield (foil + braid), high‑flex industrial PVC jacket

• Environment: High‑EMI industrial locations (power plants, oil/gas, turbines)

3. Key Features

• MicroNet® Compliant – Native compatibility with Woodward MicroNet Plus systems

• High‑Density Design – Combines analog and discrete signals in one cable

• Double Shielding – Foil + braid for 100% EMI/RFI coverage

• Precision Length – 16 ft (4.88 m)

• Molded Keyed Connectors – Factory‑terminated, no field wiring

• Wide Temperature Range – −40 °C to +85 °C

• Industrial Durability – Oil, chemical, and abrasion resistant

• Plug‑and‑Play – Direct connection to 505/505E/505XT and MicroNet I/O

• CE/UL/RoHS – Global compliance certifications

4. Technical Specifications

• Part Number: 5417-176

• Manufacturer: Woodward (USA)

• Product Type: MicroNet High‑Density Analog/Discrete Cable Assembly

• Length: 16 ft (4.88 m)

• Conductors: Multi‑pair twisted (analog + discrete)

• Shielding: Double (foil + braid), 100% coverage

• Connectors: Woodward proprietary MicroNet (molded/keyed)

• Jacket Material: High‑flex industrial PVC (oil/chemical resistant)

• Voltage Rating: 120 V AC/DC maximum

• Operating Temperature: −40 °C to +85 °C

• Weight: Approx. 0.4 kg (0.88 lbs)

• Certifications: CE, UL, RoHS

• Compatibility: 505/505E/505XT, MicroNet Plus controllers, 5417‑series I/O modules

5. Applications

• Turbine Control Systems – Linking 505 governors to MicroNet I/O panels

• MicroNet System Expansion – Connecting master controllers to remote analog/discrete I/O

• Power Generation – Steam/gas turbine signal wiring (speed, load, temperature)

• Oil & Gas – Compressor and turbine skid control networking

• Engine Control – Reciprocating engine governor I/O interconnection

6. Ordering Information

• Part Number: 5417-176

• Description: Woodward 5417-176 MicroNet High‑Density Analog/Discrete Cable Assembly, 16 ft (4.88 m), Double Shielded, for 505/MicroNet Systems
