Bently Nevada 125388-01H

Half‑Height Module Internal Chassis (for 3500/05 Rack)

1. General Information

Manufacturer: Bently Nevada (Baker Hughes)

Model: 125388-01H

Type: Half‑height module internal chassis (mechanical housing)

Applicable Rack: 3500/05 half‑height 7‑slot rack

Function: Provides mechanical structure, shielding, and backplane interconnect for 3500 half‑height monitor modules (e.g., 3500/25, 3500/60, 3500/61)

2. Physical Specifications

Dimensions (L × W × H): 222 mm × 246 mm × 20 mm

Weight: 0.22 kg (approx.)

Material: High‑grade industrial metal, flame‑retardant, vibration‑resistant

3. Environmental Ratings

Operating Temperature: –40 °C to +70 °C

Storage Temperature: –40 °C to +85 °C

Humidity: 5%–95% RH, non‑condensing

4. Compatibility & Features

Compatibility: All Bently Nevada 3500 series half‑height modules

Design: Half‑height, single‑slot installation

Mounting: Hot‑swap capable (backplane connector, supports online module replacement)

Construction: Reinforced for high temperature/high humidity stability (H = High‑grade)

5. Certifications

CE, UL, CSA, ATEX (selected versions)

6. Difference between 125388‑01 and 125388‑01H

125388‑01: Standard half‑height chassis

125388‑01H: Enhanced high‑grade version for more demanding environmental conditions
