140CFI00800

Modicon Quantum CableFast Terminal Block General Information Manufacturer: Schneider Electric Model: 140CFI00800 Product Type: 8 Points Non-fused Analog Input Terminal Block Applicable System: Modicon Quantum 140 Series PLC

Description



140CFI00800

Modicon Quantum CableFast Terminal Block

General Information

Manufacturer: Schneider Electric
Model: 140CFI00800
Product Type: 8 Points Non-fused Analog Input Terminal Block
Applicable System: Modicon Quantum 140 Series PLC

Product Description

140CFI00800 is a DIN rail mounted CableFast wiring terminal block designed specially for analog input signals. It connects with Quantum analog modules via D-Sub 50 cable, providing convenient field wiring for 8-channel analog input signals. This model is non-fused type, equipped with independent shielding terminals, effectively reducing signal interference and ensuring accurate and stable analog signal transmission.

Main Technical Specifications

  1. Channel Quantity: 8 analog input channels

  2. Connection Interface: D-Sub 50 pin connector

  3. Field Terminal: Captive screw terminal

  4. Protection Type: Non-fused design

  5. Wiring Structure: Equipped with independent signal positive, negative and shielding terminals

  6. Installation Method: Standard 35mm DIN rail mounting

  7. Operating Temperature: 0℃ ~ +60℃

  8. Storage Temperature: -40℃ ~ +85℃

  9. Protection Grade: IP20

  10. Applicable Wire Size: 0.2-4mm²

Core Features

  1. Compact 8-channel design, save control cabinet installation space

  2. Built-in shielding terminal, greatly improve anti-interference ability

  3. Non-fused structure, simple circuit structure and easy maintenance

  4. Vibration resistant screw terminals to ensure long-term stable connection

  5. Clear terminal marking, convenient wiring and daily inspection

  6. Perfect matching with various 8-channel analog input modules

Application Scope

Mainly used with 8-channel universal analog input modules, RTD and thermocouple temperature input modules. Widely applied in electric power, chemical industry, water treatment and other industries for field analog sensor signal connection.

Compatibility

Fully compatible with Modicon Quantum 140 series 8-channel analog input modules, not suitable for digital input and output modules.
