SCHNEIDER ELECTRIC EXECH10A MCH SPRING CHARGING GEAR MOTOR 100/125 VAC

SCHNEIDER EXECH10A (MCH) is a spring charging gear motor assembly for Schneider EasyPact EXE series air circuit breaker (ACB), operating voltage 100‑125V AC. This breaker charging motor unit integrates small AC motor, reduction gearbox and limit switch assembly, used to automatically charge the breaker closing spring after circuit breaker opening. This gear motor completes spring charging within a short time, with built-in travel limit cut-off, overcurrent protection and mechanical interlock. This gear motor assembly is compatible with EasyPact EXE air circuit breakers, widely used in marine power switchboard, industrial substation and power distribution panel.

This unit is a vital power distribution spare part for low voltage air circuit breaker overhaul. The electrical spare part receives control signal to drive gear mechanism and tension the closing spring. The electrical spare part sends feedback status signal via auxiliary contacts to PLC and SCADA system. The electrical spare part can replace faulty motor assembly to restore breaker automatic spring charging function.

It delivers reliable air circuit breaker spring charging control for power distribution systems. The air circuit breaker spring charging control performs automatic spring charge for breaker closing operation. The air circuit breaker spring charging control stops motor automatically once spring reaches full tension. The air circuit breaker spring charging control prevents repeated over-charging and protects motor against overload damage.

EXECH10A gear motor is installed inside EasyPact EXE air circuit breaker compartment. It is original Schneider spare part for low voltage ACB maintenance.
