General Information

• Manufacturer: Schneider Electric

• Model: 140CFD03200

• Product Type: CableFast 2/3‑Wire Digital Input Terminal Block, Fused

• System: Modicon Quantum 140 Series I/O

• Function: 32‑point digital input wiring interface with group fusing

Description

Key Specifications

• Total Points: 32 digital inputs

• Grouping: 4 groups × 8 points

• Connector: 1× female SUB‑D 50 (to PLC)

• Field Terminals: 3 screws per point (96 total), captive type

• Fusing: 0.8 A per group (replaceable)

• Wiring: 2‑wire or 3‑wire input

• Mounting: Standard 35 mm DIN rail

• Wire Range: 0.2–4 mm² (AWG 24–12)

• Operating Temp: −10°C to +60°C

• Protection: IP20

• Weight: ~0.67 kg

• Warranty: 18 months

Features

1. 2/3‑Wire Support: Flexible for NPN/PNP, sink/source inputs.

2. Group Fusing (0.8 A): Isolates faults; protects module and wiring.

3. 3 Terminals per Point: Dedicated common/+/- for easy field wiring.

4. Captive Screws: Vibration‑resistant, no loose parts.

5. CableFast: Fast SUB‑D 50 connection, reduces cabinet wiring time.

Compatibility

• Digital Input Modules: 140DDI35300, 140DDI85300, 140DAI35300, etc.

• Not for analog or thermocouple modules (e.g., 140ATI03000).

Application

• Industrial control panels, process automation, manufacturing, power, water treatment.

• Connects 2/3‑wire sensors, limit switches, pushbuttons to Quantum PLC inputs。
