ICS Triplex T8424 Digital Field Terminal Assembly FTA Board for Trusted TMR SIL3 SIS Safety System
May 15, 2026

ICS Triplex T8424 Digital Field Terminal Assembly FTA Board for Trusted TMR SIL3 SIS Safety System

T8424 is a Trusted TMR 120 VAC Digital Input Module for the Trusted T8000 Safety Instrumented System (SIS) by ICS Triplex / Rockwell Automation。 It provides 40 channels of 120 VAC digital input with Triple Modular Redundancy (TMR) and per‑channel 1oo2D voting, certified for IEC 61508 SIL 3 / SIL 4 safety applications。

Description


1. Introduction

T8424 is a Trusted TMR 120 VAC Digital Input Module for the Trusted T8000 Safety Instrumented System (SIS) by ICS Triplex / Rockwell Automation
It provides 40 channels of 120 VAC digital input with Triple Modular Redundancy (TMR) and per‑channel 1oo2D voting, certified for IEC 61508 SIL 3 / SIL 4 safety applications。
  • Purpose: Monitor discrete 120 VAC field devices (switches, contactors, relay contacts)

  • Architecture: TMR (3‑2‑0) + 1oo2D per‑channel voting

  • Safety: IEC 61508 SIL 3 / SIL 4 certified

  • Coating: Standard version (non‑coated); T8424C = acrylic conformal coated

  • Temp Range: 0 °C to +60 °C (T8424C: –40 °C to +70 °C)

  • Channels: 40 × 120 VAC digital inputs

  • Isolation: 2500 V DC optical (channel–channel, channel–system)

  • SOE: 1 ms resolution sequence‑of‑events logging

  • Hot‑Swap: Yes (online replacement)


2. Product Overview

The T8424 is a compact, 56 mm wide T8000 chassis module designed for 120 VAC field input monitoring in standard industrial environments
  • 40 × 120 VAC digital input channels (sink/source configurable)

  • Fully triplicated (TMR) input processing (three independent measurement lanes)

  • Sigma‑delta ADCs for high‑precision voltage sampling

  • Per‑channel 1oo2D voting for fault detection

  • Optical isolation (2500 V DC) between field and backplane

  • Onboard SOE (1 ms) for event time‑stamping

  • Independent line monitoring (open/short circuit) per channel

  • Front‑panel LEDs for channel status and module health

It mounts in T8100 / T8400 Trusted Controller Chassis and communicates via the Trusted Backplane Bus (TBB)

3. Specifications

3.1 Mechanical

  • Form Factor: T8000 chassis module, 56 mm wide, 6U

  • Dimensions (H×W×D): 255 mm × 56 mm × 210 mm

  • Weight: 1.3 kg (2.87 lbs)

  • Mounting: T8100 / T8400 chassis slots 1–16

  • Connectors: Front‑panel terminal blocks (TB1–TB5, 8 channels each)

  • PCB Protection: Standard (non‑coated); T8424C = acrylic conformal coating

3.2 Electrical

  • System Supply: 20–32 V DC (nominal 24 V DC)

  • Power Consumption: ≤ 5 W

  • Input Channels: 40 × 120 VAC digital inputs

  • Input Voltage Thresholds:

    • Logic 1: 90–150 V AC

    • Logic 0: <30 V AC

  • Input Current: ~4 mA per channel (at 120 V AC)

  • Input Type: Sink (NPN) / Source (PNP) configurable

  • Isolation: 2500 V DC optical barrier (channel–channel, channel–system)

  • Backplane Interface: Trusted Backplane Bus (TBB), TMR

3.3 Functional

  • Voting: 1oo2D per channel (triple measurement + comparison)

  • SOE Resolution: 1 ms (per channel state change)

  • Diagnostics:

    • Open‑circuit detection (per channel, with line resistor)

    • Short‑circuit detection (per channel)

    • Onboard BIST (Built‑In Self‑Test)

    • Fault logging to system HMI

  • Response Time: ≤ 2.0 ms (channel to backplane)

  • Data Integrity: BER < 10⁻¹²

3.4 Environmental

  • Operating Temperature: 0 °C to +60 °C (standard)

  • Storage Temperature: –40 °C to +85 °C

  • Humidity: 5–95 % RH, non‑condensing

  • Altitude: ≤ 2000 m

  • Vibration: IEC 60068‑2‑6 (1 g, 10–150 Hz)

  • Shock: IEC 60068‑2‑27 (15 g, 11 ms)

3.5 Safety & Certification

  • Safety Standard: IEC 61508 SIL 3 / SIL 4

  • Certifications: CE, UL, CSA, ATEX II 3G Ex ec IIC T4 Gc, IECEx

  • Fault Tolerance: TMR (3‑2‑0), 1oo2D per channel

  • PFHd: < 8.0 × 10⁻¹⁰ / h (SIL 4)


4. Front Panel & Indicators

  • PWR (Green): On = Module power OK; Off = No power

  • RUN (Green): On = Module active; Flashing = Initialization / BIST

  • FAULT (Red): On = Module/channel fault; Flashing = Minor fault

  • COM (Green): Flashing = Backplane communication active

  • TB1–TB5: 5 × terminal blocks (8 channels each, 120 VAC inputs)

  • FG: Functional Ground (chassis earth)


5. Installation & Wiring

  • Chassis Mounting: Align with empty slot in T8100/T8400 chassis, insert firmly, tighten front‑panel screws (torque 0.8–1.0 Nm)

  • Field Wiring: For each terminal block, connect 120 VAC L to group common terminal, field device output to channel input terminal, device common to 120 VAC N

  • Wire Gauge: 16–22 AWG stranded wire; torque terminals to 0.5–0.6 Nm

  • Line Resistors: 10 kΩ for open‑circuit monitoring (per channel)

  • Hot‑Swap: Supported; system auto‑detects new module without shutdown


6. Operation & Diagnostics

  • Power‑up: PWR ON; RUN flashes during self‑test (5–10 s)

  • Normal Operation: PWR + RUN steady GREEN; FAULT OFF; COM flashing

  • Fault Conditions: FAULT ON = critical fault (channel short/open, TMR mismatch); FAULT Flashing = minor fault (single‑lane mismatch)

  • SOE Logging: All state changes time‑stamped (1 ms) and stored in system memory


7. Ordering Information

  • T8424: Standard 40‑Ch 120 VAC DI (0 °C … +60 °C)

  • T8424C: Conformal coated, –40 °C … +70 °CRockwell Automation

  • TC‑8424: Terminal Block Cable Kit (field wiring)
